Latitude E6430 ATG Front and Back View
Figure 5. Front view
1.microphone
2.display release latch
3.camera
4.camera status light
5.display latch
6.display
7.power button
8.eSATA/USB 2.0 connector
9.USB 3.0 connector
10.powered USB 3.0 connector
11.volume control buttons
12.wireless switch
13.optical drive
14.ExpressCard slot
15.fingerprint reader
16.Secure Digital (SD)
17.contactless smart card reader
18.touchpad buttons (2)
19.touchpad
20.trackstick buttons (3)
21.trackstick
22.keyboard
23.device status lights (hard disk, battery, and wireless)
