LAMP UNIT (LAMP/CAGE MODULE) FOR PROJECTOR

INSTALLATION MANUAL

Model AH-50001/AH-50002

CAUTION:

Potential hazard of glass particles if lamp ruptures. Please have an EIKI Authorized Dealer or Service Center replace lamp if rupture occurs.

Do not remove the lamp unit directly after operation of the projector. The lamp may be extremely hot. Wait at least one hour after the power cord is disconnected to allow the surface of the lamp unit to fully cool before removing the lamp unit.

It is recommended that the lamp be replaced when the remaining lamp life becomes 5% or less, or when you notice a signifi- cant deterioration in the picture and color quality. The lamp life (percentage) can be checked with the on-screen display.

Hg LAMP CONTAINS MERCURY For State Lamp Disposal Information



www.lamprecycle.org or 1-800-242-3454

U.S.A. ONLY

5 Insert the new lamp unit.

Press the lamp unit firmly into the lamp unit compartment. Fasten the securing screws.

Be sure that AH-50001 and AH-50002 are re- spective type.

6 Replace the lamp unit cover.

Align the lamp unit cover and slide it to close. Then tighten the user service screw to secure the lamp unit cover.

Info

AH-50001

AH-50002

For Lamp 1

For Lamp 2



Compartment for

Compartment for

User service

Removing and Installing the Lamp Unit

STANDBY-ON button

If the lamp unit and lamp unit cover are not cor- rectly installed, the power will not turn on, even if the power cord is connected to the projector.

AH-50001

AH-50002

screw

Info

Make sure that you remove the lamp unit by the handle. Do not touch the glass surface of the lamp unit or the inside of the projector.

To avoid injury to yourself and damage to the lamp, be sure to carefully follow the steps below.

Do not loosen other screws except for the lamp unit cover and lamp unit.

(Only the silver screws are loosened.)

1 Press on the projector or on the remote control to put the projec- tor into standby mode.

Wait until the cooling fan stops.

Warning!

Do not remove the lamp unit from the projector right after use. The lamp and parts around the lamp will be very hot and may cause burn or injury.

2

Disconnect the power cord.



Unplug the power cord from the AC socket.



Leave the lamp until it has fully cooled down



(about 1 hour).

3

Remove the lamp unit cover.

Loosen the user service screw (1) that se-

cures the lamp unit cover. Remove the lamp unit cover (2).

4 Remove the lamp unit.

Loosen the securing screws (two for each lamp) from the lamp unit. Hold the lamp unit by the handle and pull it in the direction of the arrow. At this time, keep the lamp unit horizontal and do not tilt it.

Power cord

2

1

User service screw

Handle

Securing screws

Resetting the Lamp Timer

Reset the lamp timer after replacing the lamp.

Info

Make sure to reset the lamp timer only when re- placing the lamp. If you reset the lamp timer and continue to use the same lamp, this may cause the lamp to become damaged or explode.

1 Connect the power cord.

Plug the power cord into the AC socket of the projector.

2 Reset the lamp timer. For Lamp 1

When you reset the timer for AH-50001, while

simultaneously holding down

and

,

press on the projector.

“LAMP 1 100%” is displayed, indicating that the lamp timer is reset.

For Lamp 2

When you reset the timer for AH-50002, while

simultaneously holding down and ,

press on the projector.

“LAMP 2 100%” is displayed, indicating that the lamp timer is reset.

To AC socket

Power cord

STANDBY-ON button

ENTER button

MENU button

H&V LENS SHIFT button

Printed in China 9NK5010061000 07P03-CH-NM

AH50001_2_OptionLamp.p65

1

06.12.20, 9:36 AM

Page 1
Image 1
Eiki AH-50001, AH-50002 installation manual Removing and Installing the Lamp Unit, Resetting the Lamp Timer
