Under-Counter Wine Cooler

EI24WC65G S

Top

23 5/8"

47"

2 7/8"

Door in 90° open position

Front

23 13/16"

Left

26 3/4"

241/4" 219/16"

34"

Adjustable

to 35"

Power cord location (right bottom rear)

2 3/4" 3 5/16"

90°

90°

24"

34 1/4"

min.

min.

24 1/8"

Under-Counter Wine Cooler Specifications

Product Weight – 128 Lbs.

Voltage Rating – 120V/60 Hz/15 Amps

Connected Load (kW Rating) @120 Volts = 0.15kW

(For use on adequately wired 120V, dedicated circuit having 2-wire service with a separate ground wire. Appliance must be grounded for safe operation.)

Amps @120 Volts = 6 Amps

Electrical cable supplied.

Always consult local and/or national electric codes.

Can be used freestanding, or built in under counter.

Does not require additional airspace for top, sides or rear when used in built-in application. Increase unit dimensions by at least 1/4" for recommended rough opening.

Front grille MUST remain unobstructed for proper ventilation.

Must be positioned on flat, level surface, capable of supporting entire weight when fully loaded.

Leveling legs supplied to adjust height and level unit.

Do not position unit near any heat source to ensure optimum performance.

Must be positioned to allow for 90° door swing, providing sliding shelves with necessary clearance. (Door is field reversible for right- or left-hand opening.)

When installing next to wall where handle may make contact, allow 3" clearance between opened door and wall.

Note: For planning purposes only. Refer to Product Installation Guide on the web at electroluxappliances.com for detailed instructions.

Optional Accessories

Field-Reversible Door Kit – (5303918374).
