ITEM # _______________________________________________



MODEL # _____________________________________________



PROJECT NAME # ______________________________________

VP-3 – 20 Gal. Vegetable Dryer

SIS # _________________________________________________

Greens Machine Series

AIA # _________________________________________________





VP-3 – 20 Gal. Vegetable Dryer

Greens Machine Series

601560 (VP-3)VP-3 20 Gal. Polyethylene Dryer 115 V/1p/60Hz

602024 (VP-3 220 V) VP-3 20 Gal. Polyethelene Dryer 220 V/1p/60Hz

Short Form Specification

Item No. ___________________________________

Unit to be Electrolux Dito VP-3 – 20 gal. Vegetable Dryer. Electrical characteristics to be 115 V SINGLE-phase opera- tion with single speed at 406 rpm. Heavy duty polyethylene body with an ergonomic design for easy use and cleanability.

VP-3 220 V Special Order Item



G



NEMA 6-15P



(only for VP-3

NEMA 5-15P

220 V model)

Main features

Easy to reach control knob with adjustable ON/OFF 5 minute timer.

Easy lock casters.

Easy cleaning.

Easy to load polyethylene inner basket with handle grips.

Sturdy polyethylene base totally sealed.

Balanced stainless steel driver, easy to remove for cleaning.

Polyethylene tub & lid dimensions:

Height: 32.5″

Diameter: 27″

Shipping weight: 60 lbs.

Space required: 26.5″ wide.

Built in water drain reservoir.

Inner liner capacity: 20 gal./18 lbs.

Height: 17″

Diameter: 15.68″

ETL electrical and sanitation listed.

NEMA # : 5-15P with 8′ cord.

2 year parts warranty, 1 year labor.

Optional Accessories

Extra inner liner

(PNC

653626)

Polyethylene lid

(PNC

653627)



al.G

Greens

VegetableVP-3 –Dryer20

Machine



Approval: ___________________________________________

Electrolux Professional, Inc.

www.electroluxusa.com/professional

3225 SW 42nd Street, Fort Lauderdale, Florida, 33312 • Telephone Number: 866-449-4200 • Fax Number: 954-327-6789

Series

Page 1
Image 1
Electrolux 602024 dimensions VP-3 20 Gal. Vegetable Dryer, Greens Machine Series, Greens VegetableVP-3 -Dryer20 Machine

601560, 602024, VP-3 specifications

The Electrolux VP-3,602024,601560 is a high-performance vacuum cleaner that stands out in the competitive market of home cleaning appliances. This model is designed to provide an efficient cleaning experience, catering to both residential and commercial environments.

One of the key features of the Electrolux VP-3 model is its powerful suction capability, driven by a robust motor that ensures thorough dirt and debris removal from various surfaces. Whether tackling carpets, hard floors, or upholstery, this vacuum cleaner excels in delivering optimal cleaning results. The adjustable suction settings allow users to customize the power according to the surface being cleaned, making it versatile for different cleaning tasks.

Another notable aspect of the VP-3 is its lightweight and ergonomic design, which enhances maneuverability. The vacuum is easy to carry around the house, reducing user fatigue during extended cleaning sessions. Its compact size makes storage convenient, fitting effortlessly into closets or small spaces.

The Electrolux VP-3 is also equipped with advanced filtration technology. It features a multi-stage filtration system that effectively traps allergens and fine dust particles, ensuring cleaner air quality. This is particularly beneficial for allergy sufferers, as the vacuum minimizes the release of dust back into the environment.

The vacuum cleaner comes with a range of attachments and accessories that enhance its functionality. Among these are specialized nozzles for different surfaces, a crevice tool for tight spaces, and a dusting brush that takes care of delicate items. These tools make it easy to clean every nook and cranny of your home, ensuring no area is left untouched.

Moreover, the Electrolux VP-3 boasts an energy-efficient design, which not only contributes to lower energy bills but also aligns with global sustainability efforts. Its quiet operation ensures that cleaning can be done without disturbing the peace of your household, making it ideal for nighttime cleaning or homes with young children.

In summary, the Electrolux VP-3,602024,601560 vacuum cleaner combines powerful performance with user-friendly features and advanced technology. Its efficient suction, lightweight design, effective filtration, and versatile attachments make it a reliable choice for anyone looking to maintain a clean and healthy living space. This model exemplifies Electrolux's commitment to quality and innovation in home cleaning solutions.
