Item: ______________________________



Quantity: __________________________

U Series 24" Gas

Project: ____________________________

Date: ______________________________



Approval: __________________________

Restaurant Range

Models:

U24-4L U24-4S U24-2G12L U24-2G12S U24-G24L U24-G24S

U Series 24" Gas

Model U24-4L

NOTE: Ranges suppled with casters must be installed with an approved restraining device.

Standard Features:

Large 27" (686mm) work top surface

Stainless steel front and sides

Stainless steel 5" (127mm) plate rail

Stainless steel backguard, w/remov- able stainless steel shelf

12" (305mm) section stamped drip trays w/ dimpled bottom

6" (152mm) adj. stainless steel legs

Large easy-to-use control knobs

Gas regulator

Standard on Applicable Models:

Cabinet base in lieu of oven

Ergonomic split cast iron top ring grates

Powerful 32,000 Btuh/ 9.37 kW 2 piece cast iron geometric open top burner

5/8" (15mm) thick steel griddle plate w/manual hi/lo valve control, 23" (584mm) working depth surface, Standard on right, optional on left

4-1/4" (108 mm) wide grease trough

18,000 Btuh/5.27 kW cast iron "H" style griddle burner per 12"(305mm) width of griddle

32,000 Btuh/9.37 kW cast iron "H" style oven burner

Space saver oven w/ribbed porcelain bottom & door interior, aluminized steel top, sides and back

Strong, keep-cool oven door handle

Snap action modulating oven ther- mostat low to 500° F

Nickel plated oven rack and 3-posi- tion removable oven rack guide

Optional Features:

Snap action modulating griddle con- trol 175° to 425° F

Grooved griddle in 1/2 or full plate section widths

Hot top 12" (305mm) plate in lieu of two open burners, manual valve con- trolled w/18,000 Btuh/5.27 kW cast iron "H" burner standard on left side

Low profile 9-3/8" (238mm) back- guard stainless steel front and sides

Stainless steel back for high shelf, low profile backguard or range

Additional oven racks

Chef Oven Upgrade Package: fully porcelain oven w/ribbed hearth & door liner

6" (152mm) swivel casters (4), w/front locking, leveling or non-leveling (specify)

Flanged deck mount legs

Stainless steel door for storage base models

Intermediate stainless steel shelf for storage base models

Celsius temperature dials

Restaurant Range

Specifications:

Gas restaurant series range with space saver oven. 23-5/8" (600mm) wide and 27" (686mm) deep work top surfaces. Stainless steel front, sides and 5" wide front rail. 6" (152mm) legs with adjustable feet.

Four powerful 2 piece 32,000 Btuh/9.37 kW (Natural gas), cast open burners set in split cast iron ergonomic grates. Griddle or optional hot top with cast iron "H" style burners, 18,000 Btuh/5.27 kW (natu- ral gas), in lieu of open burners. Porcelain oven bottom and door liner. Durable heavy duty oven door w/ "keep cool" handle. Heavy cast iron "H" 32,000 Btuh/ 9.37 kW (natural gas) oven burner con- trolled by even bake, fast recovery snap action modulating oven thermostat. Available with storage base in lieu of oven

Garland Commercial

Garland Commercial Ranges Ltd

Enodis UK LTD

Industries, LLC

1177 Kamato Road,

Swallowfield Way,

185 East South Street

Mississauga, Ontario

Hayes, Middlesex

Freeland, PA 18224

L4W 1X4 CANADA

UB3 1DQ ENGLAND

Phone: (570) 636-1000

Phone: 905-624-0260

Telephone: 081-561-0433

Fax: (570) 636-3903

Fax: 905-624-5669

Fax: 081-848-0041

Page 1
Image 1
