Appendix

Numeric In live and search modes, press to watch that channel full screen.

Record In live mode, press to start instant recording of all channels.

Directional and Playback Control Buttons

PTZ

Live

Go to PTZ mode.

PTZ

Adjust zoom, focus, and iris on a



PTZ channel.

Search

Start reverse playback of



recordings. Press successively to



change the fast reverse speed.

Search-PauseFrame back (I-Frame Only).

REPLAY

Live

Start playback of the latest



recordings.



(By default, the system searches



recordings in the past 30 secs. If



no recording is archived, the



system will play back the latest



one.)

PTZ

Adjust zoom, focus, and iris on a



PTZ channel.

Search

Start playback of recordings. Press



successively to change the fast



forward speed.

Search-Pause

Frame Forward.



Navigation Move up.



PTZ

Move the camera view point



up.





Navigation

Move to the right.

PTZ

Move the camera view point to the right.

Search

Play recorded videos. When pressed



successively, the search jumps forward in



time by 30 minute increments.

Search-Pause

Step forward one frame.







______________________________________________________________________________________________
