Husqvarna 62522SH owner manual Part, Description, 532

ROTARY LAWN MOWER - - MODEL NUMBER 62522SH (96143000905) - PRODUCT NUMBER 961 43 00-09

17

KEY	PART		KEY	PART
NO.	NO.	DESCRIPTION	NO.	NO.	DESCRIPTION
1	532 19 99-82	Upper Handle (Includes Foam Grip)	38	532 40 38-19	Discharge Defl ector
2	532 18 35-67	Engine Zone Control Cable	39	532 19 71-50	Handle Bracket Assembly, LH
3	532 12 51-62	Bracket, Upstop	40	532 19 71-51	Handle Bracket Assembly, RH
4	532 16 66-49	Mulcher Plug	41	532 15 04-06	Bolt, Engine
5	532 06 64-26	Wire Tie	42	532 19 30-00	Spring, Torsion
6	532 19 18-56	Handle Knob	43	873 80 04-00	Nut, Hex, Nylock
7	532 75 06-34	Screw	44	532 41 33-87	Kit, Lawn Mower Housing
8	532 19 70-19	Control Bar			(Includes Key Numbers 14, 15 and 51)
9	532 40 84-92	Rear Door Assembly	45	532 17 56-50	Rod, Hinge
10	532 12 84-15	Pop Rivet	46	532 19 40-37	Blade Adapter / Pulley
11	532 15 00-50	Screw, Self-Tapping #10-24 x 5/8	47	532 40 67-13	Blade, 22"
12	532 05 45-83	Screw, Hex Hex Head, Sems 1/4-20 x 1/2	48	532 85 10-74	Washer, Hardened
14	532 19 70-76	Back Plate	49	532 85 02-63	Washer, Helical
15	532 41 13-34	Side Baffl e	50	532 85 10-84	Screw, Machine, Hex Head 3/8
16	532 17 71-33	Discharge Baffl e	51	532 17 00-31	Front Baffl e
17	532 14 89-41	Rear Baffl e	52	532 40 47-63	Danger Decal
18	532 13 20-04	Keps Locknut 1/4-20	53	817 60 04-06	Screw
19	532 19 47-88	Rope Guide	54	532 08 83-48	Washer
20	532 18 90-08	Rear Skirt	55	532 75 15-92	Locknut, Hex 3/8-16
21	532 40 54-21	Spring, Rear Door, LH	56	532 08 86-52	Screw, Hinge 1/4-20 x 1-1/4
24	532 40 54-23	Spring, Rear Door, RH	57	532 05 17-93	Hairpin Cotter
25	532 14 52-12	Nut, Hex, Flanged	58	532 15 34-06	Lower Handle
26	532 18 41-93	Bolt, Rear Door	59	532 19 15-74	Handle Bolt
27	532 41 34-01	Wheel, Rear	60	874 76 06-12	Bolt
28	532 14 27-48	Bolt, Shoulder 3/8-16 x 1	61	532 75 15-92	Nut
29	532 40 16-30	Washer, Curved, Cylindrical	62	532 40 58-42	Debris Shield
30	532 40 65-82	Axle Arm Assembly	63	532 19 23-25	Screw, Debris Shield
31	532 19 64-01	Selector Knob	64	- - -	Engine, Briggs & Stratton, Model Number
32	532 40 98-89	Selector Spring			122T02 (Order parts from Engine manufacturer)
33	532 19 70-29	Mulcher Door	65	532 19 74-80	O-Ring
34	532 40 16-29	Spacer	69	532 19 79-91	Clip, Cable
35	532 41 06-26	Wheel Adjusting Bracket	70	532 18 27-48	Foam Grip
36	532 17 57-35	Hinge Bracket Assembly	71	532 19 09-39	Mounting Bracket, Debris Shield
37	532 15 00-78	Screw, Sems, Thread Cutting 5/16-18 x 3/4	- -	532 40 47-64	Warning Decal (not shown)
			- -	532 41 08-49	Owner's Manual, English/French

NOTE: All component dimensions given in U.S. inches. 1 inch = 25.4 mm

IMPORTANT: Use only Original Equipment Manufacturer (O.E.M.) replacement parts. Failure to do so could be hazardous, damage your lawn mower and void your warranty.
