Husqvarna LTH120 TO REPLACE MOTION DRIVE BELT See Fig, Transmission Removal/Replacement

SERVICE AND ADJUSTMENTS

TO REPLACE MOTION DRIVE BELT (See Fig. 23)

Park the tractor on level surface. Engage parking brake. For assistance, there is a belt installation guide decal on bottom side of left footrest.

•Remove mower (See “TO REMOVE MOWER” in this section of this manual.)

•Remove belt from stationary idler and clutching idler.

•Pull belt slack toward rear of tractor. Carefully remove belt upwards from transmission input pulley and over cooling fan blades.

•Pull belt toward front of tractor and remove downward from around engine pulley.

•Install new belt by reversing above procedure.

ENGINE

PULLEY

CLUTCHING

IDLER

STATION-

ARY IDLER

TRANSMISSION

INPUT PULLEY

FIG. 23

TRANSAXLE MOTION CONTROL LEVER NEUTRAL ADJUSTMENT (See Fig. 24)

The motion control lever has been preset at the factory and adjustment should not be necessary.

•Loosen adjustment bolt in front of the right rear wheel, and lightly tighten.

•Start engine and move motion control lever until tractor does not move forward or backward.

•Hold motion control lever in that position and turn engine off.

•While holding motion control lever in place, loosen the adjustment bolt.

•Move motion control lever to the neutral (N) (lock gate) position.

•Tighten adjustment bolt securely.

NOTE: If additional clearance is needed to get to adjustment bolt, move mower deck height to the lowest position.

After above adjustment is made, if the tractor still creeps forward or backward while motion control lever is in neutral position, follow these steps:

•Loosen the adjustment bolt.

•Move the motion control lever 1/4 to 1/2 inch in the direction it is trying to creep.

•Tighten adjustment bolt securely.

•Start engine and test.

•If tractor still creeps, repeat above steps until satisfied.

MOTION CONTROL	NEUTRAL
LEVER	LOCK GATE
	ADJUSTMENT
	BOLT

FIG. 24

TRANSMISSION REMOVAL/REPLACEMENT

Should your transmission require removal for service or replacement, it should be purged after reinstallation and before operating the tractor. See “PURGE TRANSMIS- SION” in the Operation section of this manual.

TO ADJUST STEERING WHEEL ALIGNMENT

If steering wheel crossbars are not horizontal (left to right) when wheels are positioned straight forward, remove steer- ing wheel and reassemble per instructions in the Assembly section of this manual.

FRONT WHEEL TOE-IN/CAMBER

The front wheel toe-in and camber are not adjustable on your tractor. If damage has occurred to affect the front wheel toe- in or camber, contact your nearest authorized service center/department.

21
