Pivot/ Slide Tube and STD. (1650), Deluxe (1450) and

X-Large (1350) Aluminum Footplates

Item







Quantity Per



Number

Note

Part Number

Description

Package

Assembly



1



1027097

Plug Button, Black (3/4")

1

1



2

A,F

1048834

Pivot/Slide Tube with Plug Button

1

1



2

A

1086481

Pivot Slide Tube with Plug Button - XLarge, 2"

1

1









Longer







2

A,F

1086482

Pivot/Slide Tube with Plug Button - 4" Longer

1

1



2

B,F

1041526

Pivot/Slide Tube with Plug Button (Steel)

1

1



2

C,F

1041527

Pivot/Slide Tube with Plug Button (Black)

1

1



2

F

1086479

Pivot Slide Tube with Plug Button, 2" Longer (Black)

1

1



2

F

1086480

Pivot Slide Tube with Plug Button, 4" Longer (Black)

1

1



2

C,E

1041527

Pivot/Slide Tube with Plug Button (Black)

1

1



2

B

1041526

Pivot/Slide Tube with Plug Button (Steel)

1

1



2

C

1041525

Pivot/Slide Tube with Plug Button - Deluxe

1

1









Aluminum







2

D

1100568

Pivot/Slide Tube with Plug Button (Black)

1

1



2

D

1100569

Pivot/Slide Tube with Plug Button

1

1









Extra Large and Standard Aluminium - 2" Longer







2

D,E,F

1100570

Pivot/Slide Tube with Plug Button - 4" Longer

1

1



2

D,G

1100571

Pivot/Slide Tube with Plug Button - Deluxe

1

1



3



44200X059

Footplate, Aluminum - Small (6-3/4" W x 6" L)

1

1



3



44200X027

Footplate, Aluminum - Medium (7-3/4" W x 6" L)

1

1



3



1043659

Footplate, Aluminum - Deluxe (8" W x 5-3/4" L) -

1

1









Right







3



1043660

Footplate, Aluminum - Deluxe (8" W x 5-3/4" L) -

1

1









Left







3



1002343

Footplate, Aluminum - Extra Large (7" W x 8-1/2" L)

1

1









- Right







3



1002344

Footplate, Aluminum - Extra Large (7" W x 8-1/2" L)

1

1









- Left







3



44200X025

Footplate, Aluminum - Extra Large (8" W x 8-1/2" L)

1

1









- Right







3



44200X026

Footplate, Aluminum - Extra Large (8" W x 8-1/2" L)

1

1









- Left







4

E

1016346

Cap, Tube End (7/8")

1

1



4

F

1027095

Plug Button, Black (7/8")

1

1



5

E,H

1006981

Spring, Leaf

1

2



5

G,H

1036120

Spring

1

2



5

F

1036123

Spring, Leaf

1

1



6

I

7930354

Package, Phillips Head Screw (#8-32 x 3/8")

1

2



7



1070168

Push Plug, Footplate

1

1



Form No. 00-68

67
