Delta 5

25 1/4

(642 m m )

OVERHEAD

VIEW

36 3/4

(933 m m )

SIDE

VIEW

C

12 1/4

A



(311 m m )







3 (76 m m )



6 (152 m m )

B

6 3/4 (171 m m )







A - Incom ing W ater C onnection





B - D rain C onnection - 2" IP S





C - E lectrical C onnection P oint





N O T E : A ll vertical dim ensions are

24 1/2

at low est point due to adjustable

(622 m m )

bullet feet and m ay be raised an

additional 2 3/4".

111/2

(292 m m )

D IS H

C LE A R A N C E

C





20



(508 m m )



39

A

(991 m m )



73/4

(197 m m )



17

B

(432 m m )



21 1/4

(540 m m )

FRONT

VIEW

211/4

(540 m m )

MACHINE DIMENSIONS

INSIDE

INSIDE

INSIDE

DOOR

WALL

CLEARANCE

CLEARANCE

CLEARANCE

OPEN

CLEARANCE

HEIGHT

WIDTH

DEPTH

DEPTH

INI











11-1/2”

20-1/4”

20.5”

36-3/4”

2”

(292 mm)

(514 mm)

(521 mm)

(933 mm)

(51 mm)











APPROXIMATE TOTAL LOAD AMPS

115/60/1

16.0





ELECTRICAL REQUIREMENT)

Rinse Booster Tank Heater

2.0 kW





Wash Pump HP

3/4





WATER REQUIREMENTS

Gallons Per Hour

46.4 (176 liters)





Flow Rate GPM

6.33 (24 liters)





Flow Pressure (PSI)

15 - 25





Waterline Size (IPS)

1/2”





Drainline Size OD

2”





SANITIZERS AVAILABLE

Sodium Hypochlorite

50 PPM





Iodiphor

12 PPM





SHIPPING DIMENSIONS

WEIGHT

CLASS

CUBE

HEIGHT

WIDTH

DEPTH













210 lbs

92.5

30

54”

30”

32”

(95 kg)



cu. ft.

(1372 mm)

(762 mm)

(813 mm)













OPERATING CAPACITY

Racks Per Hour

40





Dishes Per Hour

1,000





Glasses Per Hour

1,000





OPERATING CYCLE

Wash Cycle (Seconds)

43





Rinse Time (Seconds)

24





Dwell Time (Seconds)

18





Total Cycle (Seconds)

85





OPERATING TEMPERATURES

Wash (Minimum)

120 ˚ F / 4 9 ˚ C





Wash (Recommended)

1 4 0 ˚ F / 6 0 ˚ C





Tank Capacity

1.16 gals. (4.39 liters)





Wash Pump Capacity (GPM)

61 (231 liters)





HOW TO SPECIF EXAMPLE:

Delta 5

SHIPPING ADDRESS

6209NorthU.S.Highway25E Gray, KY 40734

MAILING ADDRESS

P. O. Box 1060

Barbourville, KY 40906

Tel: 606-523-9795

Tel: 1-888-800-5672

Fax: 606-523-1799

www.jacksonmsc.com

E-mail: customerservice@jacksonmsc.com 07610-003-61-07 (10/08)

Page 2
Image 2
Jackson Delta 5 Overhead View, Side View, Front View, Machine Dimensions, Approximate Total Load Amps, Water Requirements

Delta 5 specifications
