| Lytespan® Track Lighting System 23S20T4 | |||
Page 1 of 2 |
|
|
| Alcyon HID 20W CMH T4 GU6.5 TAL Step Spot | ||
|
|
|
|
| 6 5/8 in |
|
|
|
|
|
| [169 mm] |
|
| 1 15/16 in | 2 | 1 3/8 in |
|
| 1 |
|
| 5 11/16 in |
| |||
| [49 mm] |
| [35 mm] |
|
| |
|
|
|
| [144 mm] |
| |
|
|
|
|
|
| |
|
|
| 10 |
|
| 3 |
|
|
|
|
|
| |
| 8 |
|
| 5 1/8 in |
| 3 3/16 in |
| 7/8 in |
|
| [80 mm] | ||
|
| 6 | [130 mm] | 1/4 in | ||
|
| [23 mm] | 4 | |||
|
|
|
| [6 mm] | ||
|
|
|
|
| ||
|
|
| 6 5/16 in |
|
|
|
|
| 7 | [160 mm] |
|
|
|
|
|
|
|
| 5 | |
|
|
|
|
|
| |
|
|
|
| 9 |
|
|
3 9/16 in |
|
|
|
|
|
|
[90 mm] |
|
|
|
|
| 3 13/16 in |
|
|
|
|
|
| |
|
|
|
|
|
| [97 mm] |
Ordering Information |
|
|
|
|
| |
Catalog No. | Finish | Mounting |
| Lamps | Reflectors | |
23S20T4AL | Aluminum | For use with Lytespan Radius, Basic and Advent | 20W T4 GU6.5 Base | 23MHRF, 23MHRS, 23MHRNF | ||
23S20T4BK | Black | Track. Not compatible with extension wands | Ceramic Metal Halide | 23MHRFCCZ, 23MHRSCCZ, 23MHRNFCCZ | ||
23S20T4WH | White | or slope ceiling adapters. For monopoint |
|
| REFLECTORS SOLD SEPARATELY | |
|
| applications refer to spec sheet 6171. |
|
|
| |
Features
1.Track Attachment Fitting: Locking lever for mechanical/ electrical connection.
2.Brass Contact: Extends for connection to second circuit (Advent track only).
3.Horizontal Pivot: Wireless stem profile with 365° horizontal rotation.
Position may be locked using an allen key.
4.Vertical Pivot:
5.Fixture Housing: Die cast aluminum
6.Ballast Housing: Molded polycarbonate
7.Safety Lens: Tempered 1/8" glass. Meets or exceeds UL safety requirement for metal halide lamps.
8.On/Off Switch: Rocker switch to disconnect power to the ballast.
9.Accessory Cartridge: Hinged and captive; retaining ring included. Inside painted black to reduce glare.
10.Safety Locking Lever: Locks ballast housing to track.
Finish
All Painted finishes are baked enamel.
Accessories
Accessory Holder: Integral
Accessories: Accepts 1 snoot plus 2 lenses or 1 louver plus 1 lens.
When using 2 accessories, remove safety lens provided.
Lens: AF25, ADF25 Series
Louver: AL25HC
Reflector
Interchangeable reflectors available to allow for desired beam spread.
REFLECTORS SOLD SEPARATELY.
Lightolier is a Philips group brand
Electrical
Electronic Ballast
Input Voltage: 120V, 50/60Hz
Power Factor: High
Input Power: 24.5W
Max. Input Current: 0.20A
ANSI Code: M156
Do not use on dimming circuit.
Labels
UL, cUL
Job Information | Type: |
|
|
Job Name:
Cat. No.:
Lamp(s):
Notes:
631 Airport Road, Fall River, MA 02720 • (508)
