Lightolier 315X specifications Lytecaster Recessed Downlighting, Page 1 of, Job Information, Type

	Lytecaster Recessed Downlighting  315X
Page 1 of 2	3 3/4" (95mm) Aperture Wall Washer / Shield MR16 & ES/ESD16

4 1/2"

1/8"

1 1/2"

1" MAX

23/4"

4 1/2"

Complete fixture consists of Reflector Trim & Frame-In Kit. Select each separately

Reflector Trim		Frame-In Kit		Lamp
315STX	Stainless Steel Plated	Remodeler	300MRX	50W	MR16
315WHX	White Paint	Remodeler	301MREX	50W	MR16
		Remodeler	303MRE	37W MR16
		Remodeler	300ESX	50W	ES/ESD16 (GZ10)
		Non-IC	302MRX	50W MR16
		Non-IC	302MREX	50W MR16
		Non-IC	302ESX	50W	ES/ESD16 (GZ10)
		IC	302MRIC9X	50W MR16
		IC	302ESICX	50W	ES/ESD16 (GZ10)
		Air Seal / IC	302MRAICX	50W MR16
		Air Seal / IC	302ESAICX	50W	ES/ESD16 (GZ10)

Features

1.Housing: 25ga. galvanized steel.

2.Residence Mounting Clip: Factory-installed; zinc plated spring steel; free- hand installation. (patent # 2,184, 149)

3.Flange Housing: Cold rolled steel 22ga.

4.Adjustable Lampholder Support: 27ga. steel; Rotates 358° horizontally and 0° to 30° vertically.

5.Mounting Clips (2): 24ga. spring steel, zinc plated. Provide easy snap-in / snap-out action.

6.Lamp Guard: wall washing or clear lens for accent shield.

7.Shield: Die-formed steel ; offers dual function. First as a wall washer with wall surface. The second function is as a shielded accent light with the lamp aimed to a target and particularly effective along walls.

Frame-In Kit

Note: For complete Frame-In Kit specifications, see 300 frame specification sheets.

Accessories

Square Face Plate 300SQWH White 300SQBK Black

Labels:

CSA , UL (Suitable for damp locations.)

Job Information Type:

Job Name:

Cat. No.:

Lamp(s):

Notes:

631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710 We reserve the right to change details of design, materials and finish. www.lightolier.com © 2008 Philips Group • C0708

Lightolier is a Philips group brand
