Lytecaster Recessed Downlighting  317X































































































































































Page 1 of 2































3 3/4" (95mm) Aperture Residence Disk MR16 & ES/ESD16

5 1/2"

1 1/4"

1" MAX



21/2"

5 1/8"

Complete fixture consists of Reflector Trim & Frame-In Kit. Select each separately

Reflector Trim

Frame-In Kit

Lamp

317FGALX

Polycarbonate Ring and

Remodeler

300MRX

50W

MR16



Aluminum Painted Faceplate

Remodeler

301MREX

50W

MR16





Remodeler

303MRE

37W MR16





Remodeler

300ESX

50W

ES/ESD16 (GZ10)





Non-IC

302MRX

50W MR16





Non-IC

302MREX

50W MR16





Non-IC

302ESX

50W

ES/ESD16 (GZ10)





IC

302MRIC9X

50W MR16





IC

302ESICX

50W

ES/ESD16 (GZ10)





Air Seal / IC

302MRAICX

50W MR16





Air Seal / IC

302ESAICX

50W

ES/ESD16 (GZ10)













Features

1.Housing: 25ga. galvanized steel.

2.Residence Mounting Clip: Factory-installed; zinc plated spring steel; free- hand installation. (patent # 2,184, 149)

3.Flange Housing: Cold rolled steel 22ga.

4.Lampholder Support: 27ga. steel; Rotates 358° horizontally and 0° to 30° vertically.

5.Mounting Clips (2): 24ga. spring steel, zinc plated. Provide easy snap-in / snap-out action.

6.Frosted Lamp Guard: 2” (51mm) dia. borosilicate glass.

7.Disk: Textured polycarbonate ring with open center.

Frame-In Kit

Note: For complete Frame-In Kit specifications, see 300 frame specification sheets.

Accessories

Square Face Plate 300SQWH White 300SQBK Black

Labels:

CSA , UL (Suitable for damp locations.)

Job Information

Type:





Job Name:

Cat. No.:

Lamp(s):

Notes:

631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710 We reserve the right to change details of design, materials and finish. www.lightolier.com © 2008 Philips Group • C0708

Lightolier is a Philips group brand

Page 1
