Lightolier 330X specifications 3 3/4 95mm aperture, Lytecaster, Gimbal, ES/ESD16, 330ABX, 330ALX

03-03

3 3/4" (95mm) aperture	Lytecaster
Gimbal	Recessed Downlight
ES/ESD16

330X

Complete fixture consists of Reflector Trim & Frame-in Kit. Select each separately

REFLECTOR TRIM

330ABX	Antique Brass Plated
330ALX	Aluminum Paint
330BKX	Black Paint
330CMX	Chrome Plated
330GKX	24k Gold Plated
330SBX	Satin Brass Plated
330STX	Stainless Steel Plated
330WHX	White Paint

FRAME-IN-KIT

REMODELER	300ESX
NON-IC	302ESX
IC	302ESICX
AIR SEAL / IC	302ESAICX

LAMP

50W ES/ESD16 (GZ10)

50W ES/ESD16 (GZ10)

50W ES/ESD16 (GZ10)

50W ES/ESD16 (GZ10)

Features

Housing : 25ga galvanized steel.

Residence Mounting Clip : Factory-installed ; zinc plated spring steel ; free-hand installation. (patent # 2,184, 149)

Flange Housing : Cold rolled steel 22ga.

Adjustable Lampholder Support : 27ga. steel ; Rotates 358º horizontally and 0º to 20º vertically.

Mounting Clips (2) : 24ga. spring steel, zinc plated. Provide easy snap-in / snap-out action.

Frame-In Kit	Labels : CSA , UL
Note : For complete Frame-In Kit specifications, see 300 frame	Suitable for damp locations.
specification sheets

WE RESERVE THE RIGHT TO CHANGE DETAILS OF DESIGN, MATERIALS AND FINISH, IN ANY WAY

THAT WILL NOT ALTER INSTALLED APPEARANCE OR REDUCE FUNCTION AND PERFORMANCE.

Lightolier CFI, 3015 Louis Amos Lachine, (Quebec) H8T 1C4
