	Decorative Luna® Diffused Light 40620
Page 1 of 2	Wall Mounted Fluorescent

Cat. No.	Finish	Lamps	Width	Height	Extension	Ballast(s)	Input	Line	Input
						Type	Voltage	Current	Watts
40620N1	White	(1) 26W	11 1/4”	7 1/8”	4”	1 - 1 Lt. NPF magnetic	120V	.50 (A)	28
40620H2		Quad Tube				1 - 1 Lt. HPF magnetic	277V	.10 (A)	27
		Compact
		Fluorescent
		(2-Pin)

Features

1.Diffuser: Blown white opal glass, totally enclosed. Removable by loosening thumb screw and lifting away from backplate.

2.Ballast: Rated Class “P” thermally protected. See chart above for voltage and power factor options.

3.Backplate: Die-formed 20 ga. steel, matte white finish.

4.Thumb Screw: Turned brass.

Mounting

Fixture is provided with a mounting plate suitable for direct mounting to most outlet boxes or directly to wall surface over an outlet box.

Electrical

Fixtures require minimum 90°C rated supply wire.

Finish

All painted surfaces, baked enamel.

Labels

UL (suitable for damp locations), I.B.E.W.

Fixture conforms to Americans with Disabilities Act (ADA) Federal Regulations—Protruding Objects.

Job Information Type:

Job Name:

Cat. No.:

Lamp(s): Notes:

Lightolier a Genlyte Thomas Companywww.lightolier.com 631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710 We reserve the right to change details of design, materials and finish.

© 2002 Genlyte Thomas Group LLC (Lightolier Division) • A0902
