Lightolier 6280 specifications Lytespan Track Lighting System, Page 1 of, Par Ring Lytespot, Type

Lytespan® Track Lighting System 6280

Page 1 of 2 Par Ring Lytespot®

Catalog No.	Finishes	Mounting	Lamps	Accessories
6280	Matte White	All Lytespan Track	150W PAR-38/3	4 3/4” Dia Series Color Filters, Heat Filter, Spread Lens, Louver
		Systems		(see Lightolier Specification Sheets AF, AF2AS, AL4CC, 7650).
6281	Matte Black
6487	Matte White	Wall Washer
6488	Matte Black	Accessory

General Description

Minimal, functional form with cleanly detailed yoke and attractive Iampholder, uses 150W PAR-38 side prong lamp for maximum compactness. Permanently- tensioned trunion mounting allows Lytespot to remain fixed at any angle. Unit adjusts horizontally up to 350°, vertically up to 90°. Regressed spring clips retain filters, spread lenses, louver and adjustable ”barn door”. Wall Washer Accessory may be used to provide smooth, medium to high intensity wash of light without “scallops”, snap onto fixture housing for easy assembling.

Finish

All painted finishes baked enamel.

Electrical

Porcelain medium side-prong base connector encased in socket boot. No. 18 braided SF-1 leads.

Labels

UL; C.S.A.; I.B.E.W.

Patents

U.S. Patent No. 3,496,518. Foreign Patents granted

Job Information Type:

Job Name:

Cat. No.:

Lamp(s):

Notes:

Lightolier a Genlyte Thomas Companywww.lightolier.com 631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710 We reserve the right to change details of design, materials and finish.

© 2002 Genlyte Thomas Group LLC (Lightolier Division) • A0902
