Decorative Lumironde™ 6731WH213N1

Page 1 of 2 Ceiling or Wall Mounted Compact Fluorescent

11 1/8"

Dia.

3"

1

2

5

	6		4
	Ceiling Pan Only
Order Information			3
Catalog Number		Finish	Ballast
6731WH213N1		Matte White	Magnetic NPF 120V
6731BK213N1		Matte Black	Magnetic NPF 120V

Features	Labels
1. Diffuser: Injection molded white translucent Polycarbonate.	UL Listed, Suitable for Wet Locations.

2.Screw: Diffuser removal, tamper proof.

3.Ballast: Magnetic NPF 120V.

4.Ceiling Pan: 16 ga. die formed aluminum

5.Lamps: Compact fluorescent (by others).

6.Mounting: K.O.’s for direct mounting to 3” or 4” octagonal junction boxes.

Lamping

Compact Fluorescent: (2)13W Twin Tube 2-Pin

General Electric	Osram/Sylvania	Philips
F13BX/SPX*	CF 13DS/*	PL-S13W/ *

*Manufacturers’ color temperature designation. 13W lamp rated to start at 32˚F.

Electrical

Lampholders:	Compact Fluorescent: 2-pin, GX23 base
Ballast:	Magnetic 120V
Total Input Watts	36
Max. Line Current (Amps)	.70
Power Factor	N
Ballast Factor	1.0
THD	< 15%
Min. Starting Temps.	0°C (32°F)

Job Information Type:

Job Name:

Cat. No.:

Lamp(s):

Notes:

Lightolier a Genlyte Thomas Companywww.lightolier.com 631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710 We reserve the right to change details of design, materials and finish.

© 2002 Genlyte Thomas Group LLC (Lightolier Division) • A0902
