Lighting Systems Agili-T Pendant Direct/Indirect AGR/AGW

Page 1 of 2

2 lamp T5 (lamp over lamp) 3 lamp T5 UP/DOWN per 4’ section

Coplanar Solo Parabolic/Flat Blade Louver

48” (1219mm)48"

36”

36"

914mm

3”3" 76mm

2-7/8”

2 7/8" 74mm

2-1/16”



2 1/16"



52mm

51-1/2”54"(1308mm)

773/16"-3/16” 183mm

Ordering information

AG



R



4

































P

GR



DI



3



28



UNV



PG



































Family

Type

Luminaire





Length

AG: Agili-T

R: Direct /Indirect

4: 4’



Independant





Mount Coplanar





Solo with





Parabolic Louver





W: Direct /Indirect





Independant





Mount Coplanar





Solo with Flat





Blade Louver



Mounting

P:Pendant

Housing Finish

Wiring

Lamp Qty

Lamp

Voltage





in a cross





GR: Titanium

DI: Direct Power

section

28: 28W T5

120: 120V

2: 2 lamps

WH: White

Feed

54: 54W

277: 277V

6 wires,4 wires

(lamp over



lamp)

T5HO

347: 347V



for 347V only





3: 3 lamps



UNV:











(2 up,



Universal





1 down)



Voltage









120/277V

BallastOptions

DW: iGEN DALI

Adressable T5/T5HO with Network-2 MultiSense

Integral Motion Sensor (120 or 277V only)

DA: iGEN DALI Adressable T5/T5HO (UNV only)

PG: Electronic Program

Start T5/T5HO

Features

84.1% efficient (70% up/30% down) using T5 technology (2x F28T5).

Ultra-Light construction (4’ luminaire less than 15 lbs / 6.8 kg.) favors mobility, adds installation and remodeling convenience.

Wide indirect distribution for uniform ceiling luminance.

Construction

Parabolic louver optic made of matte aluminum / Flat Blade optic incorporates a white finish

Unique contoured louver design with integral light stop

Labels

Electrical

Standard product offering (DI version, 120V and 277V only) includes continuous 2-circuit wiring, one circuit for the upper compartment (if applicable) and one circuit for the lower compartment (if applicable). Single and double compartment luminaires can be mixed.

DA and DW available with Agili-T Network only.

18-gauge wire, maximum 10A per circuit.

Mounting

Suspension points on module: every 4’ (4’ luminaire)

Fast installation using mounting clip for Standard T-bar and Slim T-bar or for Slot T-bar (see last page).

All canopy, suspension, power feed and mounting hardware included.

Finish

Seamless color and texture finish between luminaire and end-caps.

Available with textured (white or titanium) high resistant powder-based coating.

Options and accessories

• Emergency circuiting

INDIVIDUAL CONTROL

One circuit for AGR upper compartment controls 1 ballast and 2 T5/T5HO lamps for indirect lighting ( per 4’ of luminaire).

One circuit for AGR lower compartment controls 1 ballast and 1 T5/T5HO lamp for direct lighting ( per 4’ of luminaire).

Two ballasts allow control of direct/indirect light.

Separate dimming available with Agili-T Network version.

**If electrical junction box is needed to connect emergency wiring, order AGEB, AGES or AGEO.

***18-gauge wire. Maximum of 10A per breaker. 2 circuits using 2 breakers with common neutral.

Job Information

Type:

Job Name:

Cat. No.:

Lamp(s):

Notes:

LIGHTOLIER A GENLYTE COMPANY

www.lightolier.com

CANLYTE

www.canlyte.com

TECHNICAL INFORMATION: (978) 657-7600 - (978) 658-0595



525 EDUCATION ROAD, CORNWALL, ONTARIO, CANADA K6H 6C7 - (613) 938-6221

631 AIRPORT ROAD, FALL RIVER, MA 02720 - (508) 679-8131



WE RESERVE THE RIGHT TO CHANGE DETAILS OF DESIGN, MATERIALS AND FINISH





© 2007 GENLYTE GROUP LLC (LIGHTOLIER DIVISION)

AGR-AGW-1
