![Spectral Architectural Lighting SL201A](/images/new-backgrounds/41958/419581x1.webp)
| Spectral Architectural Lighting SL201A |
Page 1 of 2 | Circle in Square Surface Round Forms |
16 1/2" (419mm)
| 5 3/4" |
| (146mm) |
| 5 3/4" |
| (146mm) |
2" | 16 1/2" |
(51mm) | (419mm) |
Ordering Guide (complete unit only)
Cat. No. |
| Lamp (circular) |
| Volt |
| Finish |
SL201APZU |
|
| 120/277V |
| Textured Black Paint & Etched Glass | |
|
|
|
Features
1.Form: The circle in square form emphasizes the lamp image on the glass. Slim ADA design.
2.Optics: Direct light distribution. Lamp image seen on glass to create the circle in square lamp optic .Etched glass supported by an aluminum turning post and secured by a heavy aluminum plate.
3.Hardware: Exposed hardware adds high design element to the form.
4.Lamp Screen: Round perforated steel around the lamps. (Medium Grey)
5.Ballast housing: Steel ballast housing contains ballast socket and glass support.
6.Glass: Glass held in place by pins in ballast housing.
Options and Accessories
For pendant units, see Circle in Square Pendant series SL200.
Dimming Ballast: Consult your Lightolier representative for more information.
Finish
All painted parts are with powder coat paint process.
Labels
UL “c/us” Listed. Suitable for damp locations.
Mounting
Mounting: Slim mounting for wall or ceiling. Suitable for mounting on standard octogonal box. Must be held in place by additional hardware. Not recommended for suspended grid ceilings.
Luminaire Weight: 8 lbs. Fixture weight is offcenter. Additional support required to keep fixture straight.
Electrical
Ballast: Electronic Program Rapid Start T5 circular lamp ballast. Universal voltage “U” ballast automatically detects 120 volts or 277 volts operation.
Lampholder: 2GX13 base, 4 Pin.
Job Information | Type: |
|
|
Job Name:
Cat. No.:
Lamp(s):
Notes:
Lightolier a Genlyte companywww.lightolier.com 631 Airport Road, Fall River, MA 02720 • (508)
© 2005 Genlyte Group LLC • B0605
