Lightolier manual Spectral Architectural Lighting SL301A, Page 1 of, Job Information, Type

Spectral Architectural Lighting SL301A

Page 1 of 2 Fluted Sconce 3 Fluted Forms 1-150W T3 Incandescent Halogen

Ordering Guide (complete unit only)

Cat. No.

SL301A

Lamp (clear halogen)	Volt	Finish
1-150W T3 (clear)	120V	Anodized Aluminum

Features

1.Form: Unique sculped curved anodized corrugated aluminum form. These natural materials create a new form of elegance in their simplicity and the manner in which light is reflected off the fluted surface. Fastened over a tex- tured black painted steel frame and back plate.

2.Optic: Wide spaced specular aluminum reflector with frosted glass protec- tive cover.

3.Electrical Design: Steel mounting plate and mounting assembly.

Finish

Anodized corrugated aluminum sheet with precise flutes. All painted parts are with powder coat paint process.

Labels

UL “c/us” Listed.

Mounting

Mounting: Black backplate mounts to a standard octagonal box.

Electrical

Voltage: 120 volts incandescent operation.

Lampholder: Double ended base.

Fixture conforms to Americans with Disabilities Act (ADA) Federal

Regulations—Protruding Objects.

Job Information Type:

Job Name:

Cat. No.:

Lamp(s):

Notes:

Lightolier a Genlyte Thomas Companywww.lightolier.com 631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710 We reserve the right to change details of design, materials and finish.

© 2002 Genlyte Thomas Group LLC (Lightolier Division) • A0902
