Control Panel Extension

Bcnet216: BCE216-3LG

•BCnet sectional control panel with two integrated loop interfaces

•Extends a BCnet sectional control panel BC216-2 or BC216-3 by two loops

•Analogue ringbus technology with unshielded detector cabling

•Easy installation, also possible later on

Fire is a permanent threat to life and property. There- fore, immediate response to a fi re is imperative. The main objective of the fi re detection control panel Series BC216 is to alarm and to react in time and, conse- quently, save lives and protect property. For decades LST have focused their aims to undertaking unrivaled efforts in order to realize new innovations in the security area. Research, development and production are loca-

ted within LST premises, thus guaranteeing flexible and reliable individual solutions.

Using a 32-bit multiprocessor system, the fi re detection control panel Series BC216 ensures topmost effi ciency and speed – prerequisites for saving lives and minimi- zing damage to property.

Description

The BCnet Sectional Control Panel/Extension BCE216- 3LG allows for the extension of a fi re detection control panel BCnet216 by two ADM loops. The extension is in- tegrated into the fi re detection control panel BCnet216 by installing it in a BCnet sectional control panel BC216- 2 or BC216-3 and connecting it to the GSSnet cabling via the GSSnet interface on the extension.

The 24V supply of the BCnet Sectional Control Panel/Ex- tension BCE216-3LG is powered from the BCnet sectio- nal control panel in whose cabinet it has been installed; it does not have a power supply or battery charger of its own. The extension is designed as compact unit and mounted on a pivoting sheet steel carrier.

The loop processing functions of the BCE216-3LG fully correspond to the functions of a BCnet Sectional Con- trol Panel BC216-2 equipped with two Loop Interfaces LIF64-1.

The ADM loop principle offers intelligent analogue ring- bus technology with bi-directional data transfer. Each loop provides for the software-aided administration of up to 198 physical address points in a maximum of 128 detector zones.

Easy parameterisation by means of PC software en- ables you to optimally adapt the control panel to your individual requirements.
