Aplicaciones

La tecnología utilizada por Luna, junto con su cápsula íntegramente fabricada en latón, produce un sonido de tipo “vintage”, extraordinariamente transparente y con una respuesta suave en las frecuencias bajas que convierten a Luna en un micrófono ideal para la grabación de voz. Luna resulta también perfecto para numerosas aplicaciones instrumentales, como por ejemplo la grabación de guitarras y bajos amplificados.

Diagrama cardioide

El patrón cardioide es el diagrama polar de uso más extendido. Con este diagrama polar, la parte posterior del micrófono no capta sonido, gracias a lo cual el ingeniero puede aislar la señal de otras fuentes o del ruido ambiente.

Características técnicas

Tipo: Condensador de diafragma grande

Diagrama polar: Cardioide

Respuesta en frecuencia: 20 Hz – 20 kHz

Sensibilidad: 16 mV/Pa (-36 dBV)

Máx. SPL (Nivel de presión sonora) con 0,5% THD: 130 dB

Nivel de ruido equivalente: 14 dB ponderado A

Impedancia de salida: 200

Carga de impedancia recomendada: >1.000

Topología de preamplificación: FET Clase A con transformador de salida

Alimentación: Alimentación phantom de 48V

Conector: XLR macho de 3 patillas

Cuerpo / Dimensiones: Lollipop, diámetro rejilla 76 mm (3"), longitud 210 mm (8,25")

Peso: 650 g (23 oz)

Accesorios incluidos: Kit de suspensión SM-4 y estuche de aluminio

luna-gd_060903

Page 4
Image 4
