Mac interface differs.
Windows user interface shown.
Set up regular backups, set your preferences, and retrieve your backup files
Optimize your drive’s performance, manage your power settings, and customize your Maxtor OneTouch button.
Protect your files with Maxtor DriveLock. Just set a personal
password to protect access to your files.
Included in the box | USB | FireWire | |
| External hard drive | • | • |
| USB cable | • |
|
| 6 to 6 pin FireWire/1394/i.LINK cable |
| • |
| External AC power adapter | • | • |
|
|
|
|
| Vertical stand | • | • |
| Installation software CD | • | • |
| User’s guide | • | • |
|
|
|
|
| Maxtor limited warranty | • | • |
|
|
|
|
Maxtor OneTouch II Drive Features |
|
Specifications
| Interface | FireWire/iLink/1394 | USB 2.0 and 1.1 |
|
|
| & USB 2.0 and 1.1 |
|
|
| Capacity | 200GB (E01A200) | 100GB (E01E100) | |
| (model numbers) | 250GB (E01G250) | 200GB (E01E200) | |
|
| 300GB (E01G300) | 300GB (E01H300) | |
|
| 500GB (E01G500) | 500GB (E01H500) | |
| RPM | 7200 RPM |
|
|
| Cache Buffer | |||
|
| |||
| Platform | PC and Mac |
|
|
Integrated Interface
FireWire, IEEE 1394, i.LINK and
•External
•Supports serial bus data transfer rates of 100, 200 and 400 Mb/sec
USB 2.0 and 1.1 compliant
•External
•Supports data transfer rates up to 480 Mb/sec
Performance
Average seek time:
• ≤ 9.0ms
Sustained transfer rate (maximum):
•
•
Bus transfer rate (maximum):
•
•
Environmental Specifications
Operating temperature: 5º C to 35º C (41º F to 95º F)
Physical Specifications
Dimensions: 1 5/8 x 5 1/2 x 8 5/16 inches (41 x 140 x 220 mm)
Weight: 3.1 lbs (1.38 Kgrams)
Power Requirements
AC Input Voltage:
Input Frequency:
System Requirements
| Win98SE | Win ME | Win2000 | WinXP | MacOS9 MacOSX | |
|
|
|
|
|
|
|
Maxtor DriveLock | • | • | • | • | FW** | • |
security feature |
|
|
|
|
|
|
Retrieve latest version | • | • | • | • | FW** | • |
of backup |
|
|
|
|
|
|
Retrieve past versions | • | • | • | • |
|
|
of backup |
|
|
|
|
|
|
OS bootable from drive |
|
|
|
|
| FW** |
FireWire/1394/i.LINK | • | • | • | • | • | • |
USB 1.1 or 2.0 | • | • | • | • |
| • |
PC:
•Pentium III , 500 Mhz equivalent processor or higher
•Windows® 98SE, ME, 2000 Professional† or XP Home and XP Professional Editions.†
•128MB RAM or more as required by operating system
•
•Internet connection (for system updates)
Mac:
•Mac OS 9.1** or later, or OS X
•OS 9: 64MB of RAM or more as required by operating system
•OS X: 128MB RAM or more as required by operating system
•
•Internet connection (for system updates)
Default installation | • | • | • | • | |
backs up |
|
|
|
| |
drives |
|
|
|
| |
|
|
|
|
|
|
|
|
|
|
|
|
Interface Requirements
USB: | FIREWIRE | |
• Available USB 1.1 or 2.0 port | • Available FireWire/1394/ | |
| i.LINK port | |
|
|
|
|
|
|
For support or information, call us at
*For Windows OS versions Win 98SE, Win ME, Win 2000, Win XP † software does not work with the Server editions of these operating systems. ** FW: with FireWire interface only.
For purposes of measuring storage capacity, a gigabyte (GB) equals 1,000,000,000 bytes. Total accessible capacity varies depending on operating environment. Maxtor OneTouch is an element of your overall data protection plan.
©2004 Maxtor Corporation. Maxtor, What drives you and the Maxtor stylized logo are registered trademarks, and Maxtor OneTouch and Maxtor DriveLock are trademarks, of Maxtor Corporation. Dantz, the Dantz logo, and Retrospect are registered trademarks of Dantz Development Corporation. (Dantz Development Corporation: U.S. patents 5,150,473 and 5,966,730. Other patents pending.) Mac and the Mac logo are trademarks of Apple Computer, Inc., registered in the U.S. and other countries. The
