PMC-3X Specifications

FM Radio: 88-108 MHz (mono)

Audio Output to Headphone: 150mW / 16-32

FRS radio IN/OUT jack: Impedances 1k / 16 Ohms

Ohms

PTT input jack: NO PTT SW

Headphone Impedance: 16 or 32 Ohms

AUX input jack: Stereo L+R inputs 10 / 10 Ohms

Mic Impedance: 600 Ohms – Unidirectional

Controls: High / Low Volume adjust button,

Electret Condenser

Search / Reset FM Tuner adjust button,

Housing Material: Cases and headset, both high

OFF / Intercom / FM select switch, VOX adjust

impact ABS plastic

knob for radio muting audio level select

Size: 4.0" x 2.75" x .65” (102 x 70 x 17 mm)

Connectors: Passenger, Driver, Aux in, Ext. PTT,

Weight: 3.1 oz. (79 grams)

2-way Radio (3.5mm TRS jacks); 5 VDC input,

Batteries: 3 AAA, 1.5V Batteries

3.5mm TS jack (TIP = NEG)

Specifications subject to change without notice







PLEASE READ BEFORE USING YOUR PMC-3X

Before you connect your intercom earphone and mic, it is important to make sure that the metal parts of the plug and jack are clean and dry, especially in cold weather. To prevent dirt or moisture from damaging your intercom, always wipe the metal part of the plugs with a clean, dry cloth before plugging in. We also suggest that you use a tuner cleaner spray (available at any electronics supply store) to spray the plugs and jacks once a month to keep the contacts clean.

SERVICE FOR YOUR NADY COMMUNICATOR

(U.S.) Should your motorcycle communicator require service, please contact the Nady Service Department via telephone at (510) 652-2411 or e-mail to service@nady.com for a Return Authorization (R/A) Number and a service quote (if out of warranty). Make sure the R/A Number is clearly marked on the outside of the package and enclose a cashier’s check or money order (if not prepaid with a credit card). Ship the unit prepaid to: Nady Systems, Inc., Service Department, 6701 Shellmound Street, Emeryville, CA 94608. Include a brief description of the problems you are experiencing.

The warranty card enclosed with this system contains additional valuable warranty and service information. Keep it in a safe place for future possible reference. Do not attempt to service this unit yourself as it will void the warranty.

(International) For service, please contact the Nady distributor in your country through the dealer from whom you purchased this product.

Contact your dealer or Nady Systems for more information on our complete line of advanced products for your motorcycle communication needs.

NADY SYSTEMS, INC.

6701 Shellmound Street, Emeryville, CA USA 94608 Tel: 510/652-2411 Fax: 510/652-5075 www.nady.com

with

FM RADIO

NADY PMC-3X

Driver-Passenger

Personal Motorcycle Communicator

OWNER’S MANUAL

MOTORCYCLE

INTERCOM

Page 1 Page 2
Page 1
Image 1
Nady Systems PMC3X specifications Motorcycle Intercom, PMC-3X Specifications, Please Read Before Using Your PMC-3X
Page 1 Page 2

PMC3X specifications

The Nady Systems PMC3X is a sophisticated personal monitor system that has gained recognition in the audio industry for its versatile features and advanced technology. This compact unit is designed for performers who require high-quality audio monitoring while on stage. With a focus on user-friendliness and performance, the PMC3X delivers a range of functionalities that meet the needs of both novice and professional musicians.

One of the standout features of the PMC3X is its robust wireless capabilities. Utilizing UHF technology, the system offers a wide frequency range, ensuring reliable signal transmission and minimizing interference. This is particularly important in live performance environments where multiple wireless devices may be in use. Users can enjoy a stable connection and clear audio without the hassle of tangled cables, granting them the freedom to move around the stage effortlessly.

The PMC3X is equipped with a powerful onboard amplifier, which allows it to drive various types of monitoring systems, including in-ear monitors and stage wedges. This flexibility makes it suitable for different performance settings, whether in small venues or large arenas. The unit also features a built-in limiter, which helps to protect the ears of performers from sudden loud bursts of sound, ensuring a safe listening experience.

Another notable characteristic of the PMC3X is its intuitive user interface. The front panel includes easy-to-read LED indicators that provide vital information regarding battery status, signal strength, and input levels. Additionally, the system offers multiple input options, including a ¼-inch jack and XLR connectors, making it compatible with various audio sources.

The Nady Systems PMC3X also supports a range of audio formats, including mono and stereo inputs, providing users with the ability to customize their monitoring mix according to personal preferences. This versatility is particularly beneficial during live performances where different musicians may require tailored audio settings.

Furthermore, the PMC3X is designed with portability in mind. Its lightweight and compact design make it easy to transport, making it an ideal choice for touring musicians. Whether on stage, in rehearsal studios, or recording sessions, the PMC3X stands out as an indispensable tool for enhancing audio monitoring.

In summary, the Nady Systems PMC3X is a reliable personal monitor system filled with features that elevate live performances. With its advanced wireless technology, powerful amplification, user-friendly interface, and versatility in audio formats, it continues to be a popular choice among musicians seeking superior sound quality and performance.
