Features, Instructions

& Technical Data

ProPower Series™ Speakers

PTS1015

Two-WaySpeaker

Congratulations!

You have just purchased one of the finest speakers on the market today. The ProPower Series™ was developed using the expertise of professional sound engineers and working musicians. You will find your new NADY AUDIO speaker has superior performance and greater flexibility than any other speaker in its price range.

We recommend that you read this instruction sheet carefully to get the most out of your new unit. Thanks for selecting NADY AUDIO and the PTS1015 as your choice in speakers.

Ruggedly built, exceptional sound, most affordably priced – the

ProPower Series™ from Nady Audio delivers the best value in small

PA speakers

F E A T URES

AND SPECIFICATIONS

• Full range, 2-way speaker with 15” woofer, 5”x15” horn

• Binding post (banana jack) and two 1/4” (6.3 mm) jack inputs

• Peak power rating: 500W (250W RMS)

• Base mount inserts for mounting on speaker stands

• Trapezoid speaker enclosure

• 8Ω impedance

• All horns with high compression piezo drivers

• Sensitivity (1W/1M): 91.5dB

• Durable black carpet cover

• Weight: 41 lbs (15.3 Kg)

• Heavy duty plastic protective corners

• Dimensions (WDH): 18.1"x 14.9"x 27.2" (46 x 37.8 x 69.2 cm)

• Integrated recessed carrying handles for easy handling



WA R N I N G SIMPORTANTSAFETYINSTRUCTIONS

When using this speaker, basic precautions should always be taken, including the following:

•Read all instructions before using the product.

•This product may be capable of producing sound levels that could cause permanent hearing loss. Do not operate for a long period of time at a high volume level or at a level that is uncomfortable. If you experience any hearing loss or ringing in the ears, you should consult an audiologist.

•To avoid damage to the drivers, never overload the speaker.

•To avoid the risk of fire, do not ever expose the speaker to a source of naked flames. Also, it should be located away from heat sources such as radiators, heat vents, or other devices (including amplifiers) that produce heat.

•The product should be positioned so that proper ventilation is maintained.

•This speaker is designed for indoor use only. Do not expose to weather or high humidity, rain, etc.

•Care should be taken so that objects do not fall into, and liquids are not spilled through, the enclosure’s openings. Do not place containers of liquids on the speaker.

•Don’t place any heavy appliance or object (>130lbs/60kg) on the speaker enclosure.

•This unit is to be installed by qualified personnel only.

•This speaker is only to be used with power amplifiers complying with the safety requirement of EN or IEC60065.

•This product should be serviced by qualified service personnel if:

A.Objects have fallen into, or liquid has been spilled onto the product.

B.The product has been exposed to rain.

C.The product does not appear to operate normally or exhibits a marked change in performance.

D.The product has been dropped, or the enclosure damaged.

•Do not attempt to service this unit. All servicing should be referred to qualified service personnel.

Page 1 Page 2
Page 1
Image 1
Nady Systems PTS1015 important safety instructions Two-Way Speaker, Congratulations, A T U R E S
Page 1 Page 2

PTS1015 specifications

The Nady Systems PTS1015 is a versatile wireless audio transmission system specifically designed for professional performers and audio engineers seeking reliable, high-quality sound. This system is an excellent choice for live performances, theatrical productions, and various events requiring mobility and clear audio reproduction.

One of the most notable features of the PTS1015 is its dual-channel operation, allowing users to transmit two audio signals simultaneously. This ability makes the system ideal for use with multiple microphones or instruments. It employs UHF frequency operation, providing a wide and clear audio bandwidth while minimizing the risk of interference from other radio signals. The PTS1015 includes 100 selectable frequencies per channel, enabling users to find a clear channel easily, even in crowded environments.

The system is equipped with an impressive range of approximately 300 feet, making it suitable for various performance venues, from small clubs to large auditoriums. The PTS1015 features an ergonomic design that ensures ease of use and portability. The receiver is compact and designed for quick setup, allowing performers to focus on their performance rather than fiddling with equipment.

The PTS1015 uses advanced diversity technology, which helps prevent dropouts and ensures a consistent audio signal. This technology works by utilizing two separate antennas that receive signals, selecting the strongest signal for optimal audio quality. This feature is particularly crucial in dynamic environments where performers frequently move around the stage.

Another important aspect of the PTS1015 is its durable construction. The system is designed to withstand the rigors of frequent use in professional settings, ensuring longevity and reliability. Additionally, the rechargeable battery system provides hours of operation, eliminating the need to constantly replace batteries during shows.

In terms of audio quality, the PTS1015 delivers crystal-clear sound with low latency, making it suitable for music performances, speeches, and presentations. The system supports a wide frequency range, allowing for accurate and faithful reproduction of vocals and instruments, crucial for any professional audio setup.

In summary, the Nady Systems PTS1015 wireless audio system combines functionality, durability, and high-performance audio transmission. With its dual-channel operation, extensive range, ergonomic design, and advanced technologies, the PTS1015 is an excellent choice for those looking to enhance their audio experience in live settings. Whether for music, theater, or public speaking engagements, it meets the demands of professional users while offering reliable performance and sound quality.
