Nady Systems USB-5H specifications Condenser Microphone, USB Audio Interface

USB-5H

CONDENSER MICROPHONE

with USB Audio Interface

and real-time headphone monitoring

WITH

USB AUDIO

INTERFACE

Ideal for High-quality Recordings of Vocals, Acoustic Instruments, Podcasting and Online Communication

USB-5H

CONDENSER MICROPHONE

with USB Audio Interface

and real-time headphone monitoring

SPECIFICATIONS

Type:

True condenser

pressure-gradient

microphone w/ 19mm diaphragm

Frequency Response:

20 Hz – 20K Hz

Polar Pattern:

Cardioid Unidirectional

Sensitivity:

18 +/-0.5mV / Pa

Max SPL (0.5% THD):

130dB

Digital Output Interface:

USB

Analog Output:

1/8”(3.5mm) headphone jack

Resolution:

16 bit

Sampling Rate:

44.1 - 48K Hz

Power Requirements:

Power supplied from USB port

Size:

7.1” x 2” (180 x 50mm)

Weight:

5.3 oz (435g)

with USB Audio Interface	USB-5H
	CONDENSER MICROPHONE
and real-time headphone monitoring	with USB Audio Interface
	and real-time headphone monitoring

Serial Number

➤ 1/8” (3.5mm) direct headphone output with level control for latency free monitoring while recording

➤Connects directly to any computer with a USB 2.0 (or higher) input port for easy plug & play operation

➤Features large pressure-gradient condenser gold-sputtered diaphragm for warm, natural reproduction

➤Full frequency response with rich warmth and crisp, transparent audio

➤Minimal noise, wide dynamic range, and maximum SPL capacity

➤ Rugged compact construction with protective mesh grill ➤ Basemount mic holder fits any standard mic stand

➤10’ USB cable included

NADY SYSTEMS, INC.

Emeryville, California USA

Made in China
