New Holland TK4050M specifications New Holland, TK4000 Series Crawler Tractor Specifications

New Holland

TK4000 Series Crawler Tractor Specifications

TK4030V	TK4050	TK4050M	TK4060
MODEL			TK4030V	TK4050	TK4050M	TK4060
ENGINE
Type				Diesel	...........................................................................................................
Make				.......................................New Holland
Model			F5C	NEF	NEF	NEF
Cylinders / aspiration				......................4 / turbocharged and intercooled
Displacement, cu. in. (L)			195 (3.2)	274 (4.5)	274 (4.5)	274 (4.5)
Service interval∆, hours			500	600	600	600
Muffler				.....................................Under hood
Rated speed, RPM			2300	2500	2500	2500
Gross engine horsepower†			76	94	94	99
PTO horsepower†			64	83	83	88
Torque rise†, %			39	44	44	46
Emission legislation				............................................Tier III	...........................................................................................................
FUEL, AIR AND LUBRICATION SYSTEM
Fuel tank capacity, gal. (L)			21.0 (79.5)	29.0 (109.8)	29.0 (109.8)	29.0 (109.8)
TRANSMISSION
Transmission				.8x8.. non-synchronized mechanical forward-reverse shuttle
Engagement				Over-center hand lever activated
Clutch type			Single disc	Double disc	Double disc	Double disc
Clutch size				11.5 in. diameter organic driveline clutch
Ground speed range, mph (kph)			1 - 6.8 (1.36 - 11.0)	1 - 7.5 (1.7 - 12.0)	1 - 7.5 (1.7 - 12.0)	1 - 7.5 (1.7 - 12.0)
ELECTRICAL
Battery, volts / cca				12 / 800
Alternator, amps				..............................................120
Cold start aid				Grid heater
Outlets			7-pin outlet for trailer/implement lighting / Single pin (8 amp) accessory power outlet
STEERING
Steering system				Single lever Steering-O-MaticTMfull drive system control
Steering clutch	......................................................................................................			Hydraulic controlled clutch packs for each side
Clutch disks per pack				(8) 9 in. diameter clutch disks, running in oil
HYDRAULIC SYSTEM
System type				Open center
System pressure, psi (bar)				.......................................2,755 (190)
Implement pump flow, gpm (L/Min)			9.4 (35.6)	11.9 (45.0)	11.9 (45.0)	11.9 (45.0)
Steering & services pump, gpm (L/Min)			5.4 (20.4)	5.8 (22)	5.8 (22)	5.8 (22)
Remotes valves
Base equipment			3 (1 with flow control)	3	3	3
Optional			N/A	4th (1 with flow control)	4th (1 with flow control)	4th (1 with flow control)
Draft control		. . . . . . . . . . .	. . . . . . . . . . . . . . . . . . . . . .	Mechanical	. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Upper / lower limit setting			. . . . . . . . . . . . . . . . . . . . . .	. . . . . . . .Lift-O-Matic Plus		. . . . . . . . . . . . . . . . . . . . . . .
3-pt hitch lift capacity
(24" behind lift point), lbs. (kg)			4075 (1848)	4075 (1848)	4075 (1848)	4075 (1848)
PTO
PTO speed, RPM			540	540/1000	540/1000	540/1000
PTO clutch				..............................Dry, 11-in. organic plate
Engagement				Double lever mechanical

Page 1 of 2
