2.1.16 IDE Activity LED Indication

Power LED

Reset Button

SB

LAN1

LAN2

RST

PWHS

WDHD

IDE Activity

WDT Status Indication



Red LED

Description



OFF

EIDE is not active



ON

Any one EIDE device is active



Table 19: IDE Activity LED indication

2.1.17 Power LED Indication





Green LED

Description



OFF

System is not power-on or power failed



ON

System is power-on



Table 20:

Power LED indication

2.1.18 WDT LED Indication





Amber LED

Description



OFF

WDT is not enable



Blinking

WDT is enable

Table 21: WDT LED indication

28 Jumpers and Connectors

Page 36
