Specifications

Power supply:

DC 12 V



(when external power is supplied)



AC 150 V - 240 V

(when CCU is connected)

Power consumption: 8 W (during external power supply operation, camera only) 34 W (when CCU is connected)

indicates safety information.

Ambient temperature range:

14 °F to 113 °F (–10 °C to +45 °C) [Preheating required at temperatures below 32 °F (0 °C)]

Storage temperature range:

–4 °F to 140 °F (–20 °C to +60 °C) Operating ambient humidity:





Less than 85 %

Weight:

Approx. 10.36 lbs. (4.7 kg)

Dimensions:

5-5/16˝  10-1/4˝  14-3/16˝

(W  H  D)

(135  60  360 mm)





[excluding protrusions]

Basic items



1)

Pickup device:

2/3˝ 2.2 million pixel IT-CCD  3

2)

System:

GBR pickup system

3)Color separation optical system: f/1.4 prism

4)

Optical filters:

CC: 3200K, 4300K, 6300K, Cross,





Diffusion





ND: CAP, Through, 1/4, 1/16, 1/64

5)

Lens mount:

Bayonet type

6)

Output standard:

SMPTE 292M

7)

Sensitivity:

f/10.0, 2000 lux, 3200K,





white reflectance 89.9 %





(Vertical frequency: 59.94 Hz)

8)

Horizontal modulation:





More than 50 % (27.5 MHz)

9)

S/N ratio:

60 dB typ. (Y: 30 MHz)

10) Horizontal frequency:

33.716 kHz, 1125-line frame (Vertical frequency: 59.94 Hz) 28.125 kHz, 1125-line frame (Vertical frequency: 50 Hz)

11)Vertical frequency:

59.94Hz or 50 Hz, interlace

Input/output signals

1) MIC input: –20, –30, –40, –50, –60 dBm (XLR 3-pin female  )

Gain selected by camera menu

2) INCOM:

0 dBm/600 ohms



(XLR, 5-pin female  )



(Mixing is controlled separately for



PGM1 and PGM2.)

3) HD-SDI1/HD-SDI2 output:

HD signal = 0.8 Vp-p, 75 ohms (BNC) The HD-SDI2 signal output can be added to the regular images using the camera menu item setting and switched to the VF or RET image output.

4)

Prompt output:

VBS signal = 1 Vp-p, 75 ohms (BNC)



G/L input:

Tri-level SYNC or black burst (BNC)





Selected using a switch.

5)

HD RET input:

HD analog signal = 1 Vp-p, 75 ohms





(BNC)



Prompt2 output:

VBS signal = 1 Vp-p, 75 ohms (BNC)

Down converter output:

VBS or D1 signal = 1 Vp-p or 0.8 Vp-p, 75 ohms (BNC)

Input or output can be selected using the camera menu item setting.

Control

1)Power selection: EXT, OFF, CCU

2)USER 1, 2, 3: Functions specified by menu items can be allocated to the switch.

3)RET A/B selection:

For selecting the return signal

4)Monitor selection: Y/C, NAM, R, G, B

5)RET, PTT SW: RET, PTT

6)Gain selection: LOW, MID, HIGH

7)Output selection: CAM, BAR, TEST

8)White balance mode:

A, B, preset

9) Shutter speed selection:

1/100, 1/125, 1/250, 1/500, 1/1000, 1/2000

10)AWB, ABB settings

11)Menu selection

12)CALL SW

13)

INCOM:

MIC ON/OFF, receive or PGM level

14)

MIC setting:

MIC power, MIC gain, MIC1 selection

15)

Optical filter setting:





REM, LOCAL selection and LOCAL





setting

16)

Back light SW:

ON/OFF

*When the CCU is connected, the selection functions for 6) to 10) are not effective.

Weight and dimensions shown are approximate. Specifications are subject to change without notice.
