Panasonic manual PT-LB50U, PT-LB50SU, Easy wireless projection PT-LB50NTU, Quick operation

Models: PT-LB50NTU

1 2
Download 2 pages 22.36 Kb
Page 1
Image 1
PT-LB50NTU

PT-LB50NTU

Micro Portable Wireless XGA LCD Projector

PT-LB50U

Micro Portable XGA LCD Projector

PT-LB50SU

Micro Portable SVGA LCD Projector

The World’s Fastest

Wireless Transmission Projectors

Easy wireless projection (PT-LB50NTU)

World’s fastest data transfer*1

Wireless PC motion/sound streaming*2

Abundant wireless functions, including secondary display transmission and 16-window index style

Simple, user-friendly settings

Daylight View 2 technology

Looks max. 50% brighter*3

Vivid colors in a bright room

Auto operation with ambient light sensor (ALS)

High power and portability

Bright 2,000 lumens

Ultra-lightweight: 4.0 lbs/4.2 lbs (1.8 kg/1.9 kg)*4

Slim and compact design: 2-1/4˝ (57-mm) thick- ness*5

Quick operation

2-second speed start

Auto search

Real-time keystone correction

Operation assistance

Direct power off

*1 As of February 7, 2006, according to our own evaluation of wireless transmission from PC to projector. Wireless projection function is featured on the PT-LB50NTU only.

*2 Content and DVDs set with DRM (Digital Rights Management) cannot be transmitted.

*3 Comparison with Daylight View 2 turned On and Off, using an 80-inch screen and ordinary meet- ing room lighting of 400 lux. (Projector: PT-LB50NTU, screen gain: 2.6)

*4 4.0 lbs/1.8 kg for the PT-LB50U and PT-LB50SU; 4.2 lbs/1.9 kg for the PT-LB50NTU.

*5 Legs and protrudings not included.

*6 PT-LB20NTU

*7 Transmission will be slower than transmission with a computer that has the software installed. Also, certain functions may not be available.

*8 With Wireless Manager ME 3.0, you can use the projector screen as a secondary monitor for the PC. In this setup, Microsoft® PowerPoint® must be set to “Show Presenter View.”

There are no cables to connect, so projector setup is quick and easy, and you have full layout flexibility. Wireless Manager ME 3.0 software (provided) increases transmission speed by five times compared to our previous model* 6. You get fast, smooth, stress-free transmission even with large video files*2. You can copy Wireless Manager to a memory card and take it with you on a trip. This lets you enjoy wireless transmission even at presentation sites where the computer doesn’t have the software*7.

Wireless Prompter (Secondary Display) Function

This allows transmission of content other than what’s displayed on your PC. For example, you can display text documents on your PC screen while projecting slide from your Microsoft® PowerPoint ® presentation*8. You get a host of other convenient wireless transmission functions too, such as area-specified transmission and a multi-live mode for simultaneous display of up to 16 PCs.

Daylight View 2

Abuilt-in sensor measures the ambient light, and the halftone colors and brightness level are adjusted accordingly in real time. Viewing brightness is increased up to 150%*3.

The Daylight View Process

Ambient Light

Sensor (ALS)

Daylight View

Circuit

LCD Panels

Projector

Page 1
Image 1
Panasonic PT-LB50NTU manual PT-LB50U, PT-LB50SU, The World’s Fastest Wireless Transmission Projectors, Quick operation
