Planet Technology CAM-IR552 manual Specification, Related Information



CAM-IR552

SPECIFICATION

Product	50 Meter IR Camera
Model	CAM-IR552Type
Type	50meter Infrared
Image Pick-up Device	Sony 1/3“ Color CCD
Effective Picture Elements	NTSC: 811(H) x 508(V)
	PAL: 795(H) x 596(V)
Horizontal Resolution	520TVL
Minimum Illumination	0.06Lux, 0 LUX with built-in IR-LED
S/N Ratio	More than 48 dB
Auto Electronic Shutter	NTSC: 1/60s~1/100,000s
	PAL: 1/50s~1/110,000s
Gamma Characteristic	0.45
Lens Furnished	8.0mm / F2.0
Gain Control	Automatically
IR LED	High-Light LED x 12 pcs
White Balance	Automatically (2500K~9500K)
View Angle	Horizontal: 33 Degree C
	Vertical: 25 Degree C
Synchronous System	Negative sync. Internal
Video Output	1 Vp-p Composite Video / 75 Ohms.
Power Consumption	12V DC (IR off: 100mA; IR on: 460mA)
Protection Class	IP-66
Operating Temp.	-20 to 60 Degree C
Dimensions (φ x L)	90 x 250 mm
Weight	1.5Kg

ORDERING		INFORMATION
	CAM-IR552-NT	50M	Infrared Camera (NTSC)
	CAM-IR552-PA	50M	Infrared Camera (PAL)

RELATED INFORMATION

IVS-110	1-channel MPEG-4 Internet Video Server
DVR-460	4-channel MPEG-4 Digital Video Recorder
DVR-860	8-channel MPEG-4 Digital Video Recorder
DVR-470	4-channel H.264 Digital Video Recorder
DVR-1670	16-channel H.264 Digital Video Recorder
CAM-DM33-NT	Mini Dome Camera (NTSC)
CAM-DM33-PA	Mini Dome Camera (PAL)
CAM-VP38-NT	Vandal-Proof Dome Camera (NTSC)
CAM-VP38-PA	Vandal-Proof Dome Camera (PAL)
CAM-IVP52-NT	15M	Infrared Vandal-Proof Camera (NTSC)
CAM-IVP52-PA	15M	Infrared Vandal-Proof Camera (PAL)
CAM-IVP52V-NT	25M	Infrared Vari-Focal Vandal-Proof Camera (NTSC)
CAM-IVP52V-PA	25M	Infrared Vari-Focal Vandal-Proof Camera (PAL)
CAM-IR138-NT	15M	Infrared Camera (NTSC)
CAM-IR138-PA	15M	Infrared Camera (PAL)
CAM-IR338-NT	30M	Infrared Camera (NTSC)
CAM-IR338-PA	30M	Infrared Camera (PAL)
