![Legend® 3-wheel](/images/new-backgrounds/197799/1977991x1.webp)
| Legend® |
| Legend® |
|
Model number: | SC3000 |
| SC3400 |
|
|
|
|
|
|
Weight capacity: | 350 lbs. |
| 350 lbs. |
|
|
|
|
|
|
Maximum speed: | Up to 5.75 mph |
| Up to 5.75 mph |
|
|
|
|
|
|
Ground clearance: | 3.5” |
| 3.5” |
|
|
|
|
|
|
Turning radius: | 41” |
| 54” |
|
|
|
|
|
|
Overall length: | 45.375” |
| 47” |
|
|
|
|
|
|
Overall width: | 24” |
| 24” |
|
|
|
|
|
|
Wheels | 3.5” x 10” pneumatic |
| 3.5” x 10” pneumatic |
|
Front: |
|
| ||
Rear: | 4” x 10” pneumatic |
| 4” x 10” pneumatic |
|
Rear |
| Rear |
| |
|
|
|
|
|
Suspension: | Rear |
| Rear |
|
|
|
|
|
|
Transport weight |
|
|
|
|
Total w/o batteries: | 155 lbs. |
| 166 lbs. |
|
|
|
|
|
|
Heaviest piece | 61 lbs. |
| 61 lbs. |
|
when disassembled: | (Rear section) |
| (Rear section) |
|
|
|
|
| |
Drive train: | Sealed transaxle, 24 volt DC motor |
| ||
|
|
| ||
Dual braking system: | Electronic, regenerative and electromechanical |
| ||
(electronic, regenerative disc brakes) |
| |||
|
| |||
|
| |||
|
|
| ||
Power elevating seat: | Option: Yes |
| ||
|
|
| ||
Std. Seating: | CRS deluxe reclining |
| ||
|
|
| ||
Battery charger: |
| |||
|
|
| ||
Up to 25 miles |
| |||
|
|
| ||
Battery requirements: | (2) 12V deep cycle (AGM or gel cell type recommended) |
| ||
|
|
|
| |
Battery size: |
| U - 1 |
| |
Warranty: |
| |||
Colors: |
|
|
|
|
|
| Candy Apple |
| |
| Champagne Viper Blue |
| Red |
|
The information contained herein is correct at the time of publication; we reserve the right to alter specifications without prior notice. Speed & range vary with user weight, terrain type, battery charge, battery condition and tire pressure.
Benefits
•
•Top speed of up to 5.75 mph
•Maximum weight capacity of 350 lbs.
•
•Advanced new reclining
•Easily accessible tie down points (for transport of unoccupied scooter)
•Reduced length:
•New
•Easy access to rear electronics
•
•Reinforced front nose section for durability
Options
•Power elevating seat
•Forearm crutch holder
•Cane/crutch holder
•Wishbone crutch holder
•Oxygen tank holder
•Rear basket
•Safety flag
•Walker holder
•
•Saddlebag
•Lap belt
•Rearview mirror
•BackpackerTM
•Scooter double entry
•Full Platform
|
| BackpackerTM |
|
| |
|
|
|
|
| These lifts are |
|
| compatible with the |
Double entry | Legend®. |
