Audio (DVD)
Some discs have several audio tracks used for different languages or different audio formats. To change the language or audio format during playback, you can press the AUDIO button on the remote control repeatedly to select your preferred choice; or follow the below steps:
1.Press the INFO button twice.
2.Use the left/right arrow buttons to select the Audio icon.
3.Choose a language or an audio format with the up/down arrow buttons.
This option is only available if the disc offers dialog languages or audio formats. When you change the dialog language using the Info menu, it only changes the dialog language of the disc being played. When you eject the disc or switch off the unit, the language will revert to the one you selected in the language Setup menu.
Subtitles (DVD)
Subtitles are turned off by default. Press the SUBTITLE button on the remote control repeatedly during playback to select a preferred subtitle option; or follow the below steps:
1. | While the disc is playing, press INFO twice, then |
| select the Subtitles icon using the left/right |
| arrow buttons. |
2. | Select a language using the up/down arrow |
Play Mode (All Discs Except Jpeg)
1.While the disc is playing, press the INFO button twice for CD and three times for DVD.
2.Select the Play Mode icon using the left/ right arrow buttons.
3.Use the up/down arrow buttons to select an
option.
•DVD play modes: standard, program, A-B repeat, title repeat, chapter repeat. Program play mode is only available if a program list has been created (see below). Repeat mode is only available with discs that display elapsed time and remaining time. To repeat a sequence between points A and B, choose the A-B repeat option, and then follow the instructions for entering the two points.
•Audio CD play modes: standard, introscan, random, program, repeat A-B, repeat disc, repeat track.
4.To stop repeat playback, select the Play Mode icon and use the up/down arrow buttons to choose the Standard option, and press OK button.
Creating a Program List for Program Play Mode (Audio CDs and DVD Discs)
Sleep
1.Press INFO button twice for CD and three times for DVD. Select Sleep icon with the left/right arrow buttons.
2.Select one of the available options using the OK button : Off, 30, 60, 90 or 120 minutes.
Note:
This function is not available in AUX/ AUDIO IN/TUNER/iPod mode.
Introscan (CD)
This option plays the first ten seconds of each track on a CD.
1.Press the INFO button twice, then select the Play mode icon with the left/right arrow buttons.
2.Press the up/down arrow buttons to select the Intro option and press OK to start Introscan.
3.Press STOP to stop Introscan, and press PLAY to resume normal playback.
Bookmark (DVD and Audio CD)
1. Press INFO twice for CD and three times for |
The unit has a built-in tuner that allows for FM ra- dio function. The AM loop antenna allows for AM radio function.
Manual Tuning
1.Connect the FM antenna and the AM loop an- tenna at the back of the unit.
2.Press TUNER.
3.Tune a station by pressing TUNER+/-repeatedly until the desired station is found. Alternatively, you can press and hold the same buttons down for about one second to activate the automatic search function. In this mode the unit will auto- matically tune frequencies until it finds a station.
4.Repeat step 3 to tune to another radio station.
5.Press TUNER to toggle between FM and AM.
Storing Radio Stations
The unit can store up to 60 radio stations (AM/FM each 30 radio stations )in its memory. You can en- ter every single radio station yourself or the unit can store all available radio stations automatically in ascending order.
Automatic Preset Programming
1. | Press TUNER to enter the Tuner mode. |
2. | Press and hold TUNER for two seconds to start |
| automatic preset programming. |
Tips:
•When a strong FM stereo broadcasts is tuned, ST is displayed.
•When you manually tune into a weak
FM station, press AUDIO on remote control to switch from Stereo to Mono mode. This will reduce the background noise.
•If there is any interference, change the antenna’s position until ideal sound reception is obtained. TV and other electronic devices could be the cause of interference, so try to position the antenna away from them.
•A weak signal can affect the “Automatic preset programming” function’s efficiency. Adjust the antenna for better reception and a more efficient search.
iPod is a trademark of Apple Computer, Inc., registered in the U.S. and other countries.
Compatible iPod Types:
•iPod nano (1st generation) 1GB, 2GB, 4GB
•iPod nano (2nd generation) 2GB, 4GB, 8GB
•iPod nano 3rd generation (video) 4GB, 8GB
•iPod nano 4rd generation (video) 8GB, 16GB
•iPod 5th generation (video) 30GB, 60GB, 80GB
•iPod classic 80GB, 120GB, 160GB
•iPod touch (1st generation) 8GB, 16GB, 32GB
•iPod touch (2nd generation) 8GB, 16GB, 32GB
Note: Also supports iPhone when iPhone is set to “airplane mode”.
Using an Adaptor to Connecting Your iPod
1. | Open the iPod docking compartment. |
2. | Choose the iPod Dock Adaptor that fits your |
| iPod (Dock adaptors are not included with this |
| product, please use the one that was included |
| with your iPod.). |
| iPod Dock Adaptor (not included) |
Warning: To prevent damage to the unit and/or your iPod, connect or remove your iPod when the unit is powered off or the unit is not in iPod mode.
Caution: Due to the iPod limitation, not all functions of some iPod models can be controlled via the remote control of this unit. If necessary, operate on your iPod directly.
Removing the iPod Dock Adaptor
1.Remove the iPod Dock Adaptor as shown in the figure to the right.
2.Replace it with another one you need.
Notes:
•Your iPod will be charged automatically
(until fully charged) once it is connected, no matter whether the unit is in iPod mode or not.
•Make sure the software of iPod is the latest.
4.Press the RETURN button to go back to the previ- ous menu.
Playing Photos
1.In iPod Home menu, use the
,
button to select Photos and press the OK button.
“Please Navigate directly on your iPod” will appear on the screen.
2.Use the
,
and OK buttons to navigate the iPod menu lists and select a photo, press
PLAY button to begin playback.
•Press the
PAUSE button to pause playback,
press the | PLAY button again to resume |
playback. | |
•Press the
/
button to skip to the previous / next photo.
3.Press the RETURN button to go back to the previous menu.
Using an iPod Touch (e.g. 1st generation) to View Photos
1.In iPod Home menu, use the
,
button to select Photos and press the OK button. “Please Navigate directly on your iPod” will appear on the screen.
2.Touch the “Photos” selection on iPod panel, then select the photo your prefer.
5.Press RETURN button to end the photo viewing and go back to the previous menu.
Using an iPod Classic / iPod Nano to View Photos
1.In iPod Home menu, use the
,
button to select Photos and press the OK button.
“Please Navigate directly on your iPod” will appear on the screen.
2.Press the
,
button to select “Photos”, and then press the OK button to confirm.
3.Press the
,
,
,
button to select a photo, press the OK button to begin playback.
4.Press the OK button twice to activate photo showing to TV screen.
Step 4
•Press the
PAUSE button to pause playback,
press the | PLAY button to resume playback. |
•Press the
/
button to skip to the previous / next movie.
•Press the
REV/
FWD button to begin fast
reverse/forward, press the | PLAY button to |
resume normal playback. | |
4.Press the RETURN button to go back to the previous menu, then you can select another video to play.
Note:
Make sure “TV Out” in the setting of your iPod is set to “On”.
iPod Settings
1.In iPod Home menu, use the
,
button to select Settings and press the OK button.
2.Use the
,
and OK buttons to adjust Shuffle, Repeat and Language settings.
•Shuffle: Select from Shuffle Off, Shuffle Songs and Shuffle Albums.
•Repeat: Select from Repeat Off, Repeat One and
Repeat All.
•Language: Select OSD language.
3. Press the RETURN button to go back to the |
buttons. |
3. To turn subtitles off, select the Off option. |
When you change the language of the subtitles using the Info menu, it only applies to the disc currently being played. When you eject the disc and switch off the unit, the subtitles will default to the subtitle language you selected in the Languages menu.
This function may not be available on all discs.
Camera Angle (DVD)
Some discs offer different camera angles for specific scenes. To change the camera angle, press the ANGLE button on the remote control repeatedly; alternatively, you can press the INFO button twice and select the Camera angle icon with the left/right arrow buttons, and then choose the angle with the up/down arrow buttons.
If the disc was recorded using a single camera angle, this function is not available.
To use program play mode, you must first create a program list.
1.To create a program list, press the INFO button twice for CD and three times for DVD. Highlight the Play Mode option and press the up arrow to select the Program option.
2.Press OK. The Program screen is displayed.
3.The first spot in the list is highlighted. Use the number buttons on the remote control to enter a track or title/chapter number.
4.Use the arrow buttons to move to the next spot in the list. Enter the next track or title/chapter number.
5.Continue entering tracks or titles/chapters until you have completed your list.
6.Highlight the Play option at the bottom of the screen and press OK or press PLAY to start play- back. The program list will play in the order you programmed it.
| DVD. Select the Bookmark icon with the left/ |
| right arrow buttons, and press OK. A menu is |
| displayed with five bookmarks. |
2. | The first bookmark space is highlighted. Press |
| OK to set the bookmark. The bookmark is saved |
| and is indicated by the number 1. |
| Use left/right arrow and OK buttons, you can |
| set up to five bookmarks on a disc. |
3. | To start playback from a bookmark, press the |
| PLAY button on the remote control. |
4. | To delete a bookmark, highlight it and press |
| CLEAR. |
Note:
This function is only available with discs whose elapsed time or remaining time appears in the Info menu.
3. Radio frequencies will be browsed and radio |
stations stored automatically. When all the avail- |
able radio stations are stored or all 30 memory |
locations are full, the auto preset programming |
function will stop. |
Manual Preset
1.Tune to a radio station (see “Manual tuning” for details).
2.Press memory. While the Program Preset number is still flashing, input your desired preset number using the numeric buttons, then press MEMORY to store it.
Retrieving Preset Stations
1.Press TUNER to enter the Tuner mode.
2.Press CH+/
, CH–/
to search up or down for the preset stations or directly press the numeric buttons.
3. | Insert your iPod Dock Adaptor into the dock |
| until it sits firmly in place. |
4. | Turn on the unit, press the DVD/iPod button to |
| select iPOD mode. Your iPod will be connected |
| automatically, following screen appears. |
Home |
Docking system for iPod |
Welcome |
Music |
Photos |
Videos |
Settings |
Playing Music
1.IniPodHomemenu,usethe
,
buttontoselect Music and press the OK button.
2.Usethe
,
buttontoselectfromPlaylists,Artists, Albums, Songs, Genres or Composers. Press the OK button to enter.
3.Use the
,
button to navigate the iPod menu lists and select songs, press the OK button to begin playback. (You may also use the control wheel and
keys on your iPod to operate it.)
•Press the
PAUSE button to pause playback, press
the | PLAY button to resume playback. |
•Press the
/
button to skip to the previous / next song.
•Press the
REV/
FWD button to begin fast
reverse / forward, press the | PLAY button to |
resume normal playback. | |
•Press the REPEAT button to select a repeat play- back mode (a single repeat or all songs repeat). Press again repeatedly to cancel this repeat playback.
3.Touch the “ ” to confirm the photo.
4.Touch the “ Yes ” to activate iPod’s video output.
The photo will appear on the screen.
5.Press the RETURN button to end the photo viewing and go back to the previous menu.
Playing Videos
1.In iPod Home menu, use the
,
button to select Videos and press the OK button.
2.Use the
,
button to select from Movies, Music Videos, TV Shows, Video Podcasts or Rentals, press the OK button to enter. (“Please Navigate directly on your iPod” will appear on the screen if your are using an iPod touch.)
3.Use the
,
button to navigate the iPod menu lists and select a video, press the OK button to begin playback. (You may also use the control wheel and keys on your iPod to operate it.)
Please Navigate directly on your iPod
OR
Press The [CLEAR] Key
to go back to main menu
If the above screen appears, you may need to control the iPod Library directly from your iPod.
TV, VCR, SAT/Cable Box or portable audio players can be connected to AUX input jacks at the back of the unit or AUDIO IN at the front panel so that sound from the auxiliary component or the audio players comes into the unit and out through the speakers.
Connecting Auxiliary Components
Refer to “Connecting AUDIO from external sources such as TV” for details on connecting the auxiliary components to the unit.
Selecting AUDIO IN / AUX IN Mode
Press either SOURCE on the main unit or AUDIO /AUX on the remote control to select AUX IN or AUDIO IN mode.
Sound Output in Aux-In Mode
•You may change the surround setting by pressing SURROUND to select between 5.1 ch and stereo modes.
•If the auxiliary audio signal is mono, there will be no output from some speakers in 5.1CH mode.
Displaying Jpeg Files
Jpeg files are image files. Make sure that they have a resolution of less than 2 megapixels.
1.Open the disc tray.
2.Place the disc with the printed side facing up and close the disc tray. The folders on the disc will be listed in numerical order on the left side of the screen. When you highlight a folder, then press OK button. The list of pictures in the folder are listed in numerical order on the right side of the screen.
3.Select a folder using the up/down arrow buttons on the remote control.
4.Press the right arrow button to move to the file list on the right side of the screen. Use the up/ down arrow buttons to select a file. Pressplay to start picture slideshow.
•jpeg file: the unit starts the slide show with the jpeg file you have selected, then displays all the jpeg files in the same folder, then all the jpeg
files in the subfolders located in the same fold- er. You can set the amount of time a picture re- mains on the screen in the Video Setup menu.
5.Press INFO to display the Info menu during play back. Press INFO twice and select the Play Mode icon using the left/right arrow buttons. Press the up/down arrow buttons to select a play mode (Standard, Repeat Folder, Repeat Disc and Repeat Track), and press OK.
6.When the unit has played all the files, the slide show stops and the disc’s contents are dis- played again.
7.Press STOP to end playback.
Note:
•The time taken for the contents of the disc to be displayed varies according to the size and number of jpeg files on the disc. If nothing is displayed after a few minutes, the file sizes may be too large. Reduce the files’ resolution and write another disc.
•Before inserting a disc, make sure it is compatible with the unit.
•During picture slideshow, you can not zoom out a picture unless HDMI Setup is set to 480p.
Press SETUP to bring up the main menu. There are four options in the main setup menu: General Setup, Language Setup, Audio Setup and Video Setup. Press SETUP if you want to exit the main menu.
General Setup
1.Select the General Setup icon in the main menu using the left/right arrow buttons.
2.Select one of the options using the up/down arrow buttons. And press the right arrow but- ton to move to the option’s choices.
3.Use the up/down arrow buttons to highlight your preferred choice and press OK.
General Setup |
Video |
HDMI Setup |
TV Type |
Default |
Video |
Progressive Scan Output provides higher quality video. Turn on Progressive Scan if you’re using the
TV Type
Depending on the format of the DVD disc, you can choose the picture format (aspect ratio) best suited to the format of your TV screen:
•4:3 PS: reproduces a 4:3 picture without distortion.
•4:3 LB: gives best reproduction of pictures recorded in this format (i.e. with horizontal bands at the top and bottom of the screen) or in 16:9.
•16:9 (windscreen): reproduces 16:9 format films in full on a 16x9 screen.
Default
This option allows you to return the unit’s settings to the original factory settings. Any changes you have made to the unit’s settings will be reverted back to the original settings.
Once Progressive Scan has been activated, an image will only be visible on a progressive scan TV or monitor. If you choose this option and you don’t have a progressive scan TV or monitor, you may get a picture with incorrect color or no color.
Language Setup
With this menu, you can set the language for unit menus, audio, subtitles and the disc menus.
If you chose “English” during initial set-up, any menus generated by the disc are in English, and so is the language of the dialogs (if this language is available on the disc).
Language Setup |
Player Menu |
Audio |
Subtitles |
Disc Menu |
1.Select the Language Setup icon in the main menu using the left/right arrow buttons.
2.Select one of the options using the up/down arrow buttons.
3.Press the right arrow button to move to the lan- guage choices.
4.Use the up/down arrow buttons to highlight the language of your choice and press OK.
Subtitles
Select the subtitle language using up/down arrow buttons and press OK.
To change the language of the subtitles during playback, press INFO twice for DVD and use the left/right arrow buttons to highlight the Subtitle icon. Press the up/down arrow buttons or the SUBTITLE button on the remote control to select a subtitle language.
Disc Menu
To change the language of the disc menus, select the language using the up/down arrow buttons and press OK.
The language you select will only be displayed if the disc is programmed with that language.
Notes:
• If the selected language is not available |
on a disc, the disc’s language will be used |
instead. |
• If the language chosen is available, it |
is automatically selected when you |
display the subtitles or press SUBTITLE |
on the remote control. Otherwise, the |
Audio Setup
You can adapt your unit to other equipment and access specific functions with the Audio Setup menu.
1.Select the Audio Setup icon in the main menu using the left/right arrow buttons.
2.Select an option using the up/down arrow but- tons. Press OK button to move to the option’s choices.
Audio Setup |
Night Mode |
Center Delay |
Rear Delay |
Test Tone |
Night Mode
You can use this function to control the different sound levels via dynamic compression. It improves the quality of the sound track at a low volume, and quiets the loudest sounds.
Use the up/down arrow buttons to highlight the your preferred choice (Quiet, Moderate or Off) and press OK.
Test Tone
This function is used to test and adjust the volume level (gain) for each individual speaker channel. Use CH+/
, CH–/
button to select the speaker channel you wish to test and adjust. You’ll hear a test tone coming from the speaker you select. Use the VOL+/- buttons to adjust the level to your desired setting. Press OK button to exit this function.
Video Setup
1.Select the Video icon in the main menu using the left/right arrow buttons.
2.Select a menu option using the up/down arrow buttons and press OK.
3.Use the up/down arrow buttons to highlight your preferred choice and press OK.
Video Setup |
Brightness |
Contrast |
Saturation |
Slide Time |
The unit does not switch on.
•Make sure it is plugged in.
•Press the ON•OFF button on the remote control or the ON/STANDBY button on the front of the unit.
The device switches off spontaneously.
•The devices switches off automatically when it is in STOP mode for more than 30 minutes with- out any user intervention. Switch it on again.
•It might be impossible to read the disc.
•Insert the disc with the printed side facing up.
•Check that the disc can actually be played by this device.
•Check that the disc’s regional code matches the unit’s regional code. This unit’s regional code is 1.
•Clean the disc.
There is no picture.
•Check you have switched on the TV set.
•Check the connections.
•Select the AV input assigned to the unit on the
TV.
•Replace the HDMI cable with a better one. A bad HDMI cable can cause loss of video.
•Press HDMI key on remote control several times to toggle among different HD OUTPUT.
Troubleshooting
iPod does not respond to this unit.
•Remove your iPod from the docking bracket and check for obstruction on the connectors in the dock and on your iPod.
•Make sure that your iPod works properly before docking into the unit. Make sure the software of iPod is the latest. Please refer to your iPod manual for details.
I can’t find my file in the jpeg listing.
• Make sure the file name is valid.
The remote control does not work or works only intermittently.
•Check that batteries are inserted or change them.
•Aim the remote control at the unit. The infrared beam must not be blocked or interrupted.
•Check that the remote control is configured to control the device you are trying to operate with it.
The subtitles do not appear.
•Check that the DVD disc provides subtitles.
•Refer to the section on how to display sub- titles.
The disc menu language is not the correct one.
•The disc menu language has not been set up.
•The language of your choice is not available on the disc.
Additional Information
Precautions
Use
•If your unit has been stored in a cool place for any length of time, during a journey for example, wait for about 2 hours before using it.
•The openings located on the top and bottom are for ventilation and must not be obstructed.
•During thunderstorms, we recommend that you isolate the unit from the electrical supply so that it is not damaged by electrical or electromagnetic surges.
•This unit is designed for continuous use.
Switching off the unit to standby mode does not disconnect it from the mains supply. To completely isolate the equipment, remove the plug from the mains jack as some components remain connected to the electrical supply.
•If you notice any burning or smoke, disconnect the unit immediately to avoid any risk of electrocution.
•Do not attempt to look inside the unit through the disk tray opening or any other opening. You may be electrocuted or exposed to laser radiation.
•This unit is for domestic use only and must not be used for industrial purposes.
•Total or partial copying of recordings protected by copyright legislation, without the explicit permission of the holder of the rights, contravenes current legislation. Copying or downloading music files for sale or any other business purpose constitutes or could constitute a violation of copyright law.
Additional Information
Cleaning
•Use a soft, dry, clean cloth. Regularly dust the vents at the back or sides.
•Using solvents, abrasive or alcohol-based prod- ucts risks damaging the unit.
•If an object or liquid enters inside the unit, un- plug it immediately and have it checked by an authorized servicer or service center.
Handling and Caring for Discs
•Handle your discs with care. Hold the disc with your fingers at the edges or through the hole.
•Insert the disc with the label facing up (for a single-sided disc).
•Place the disc properly into the tray in the allot- ted holder.
Compatible Formats
In order to ensure playback, discs must conform with DVD or CD standards. This unit may not play some recordings or files due to differences in recording formats, software used and disc types.
DVD-Video
Digital video discs - 12 cm, single or double sided, single or dual layer. DVDs are high density optical discs on which high quality picture and audio are recorded by means of digital signals.
DVD-R, DVD-RW, DVD+R, DVD+RW
Most DVD-R and DVD+R (one recording | |
only), DVD-RW and DVD+RW discs | |
(rewritable), depending on the DVD | |
writer and discs used. Recordings using | |
DVD-R and DVD-RW discs must be made | DVD+Rewritable |
in Video DVD mode. Recordings using DVD+RW discs must be made in accordance with the specifications for DVD+RW discs with a 4.7 GB capacity.
Audio CDs
Audio CDs (12 cm).
CD-R, CD-RW
Most CD-R (one recording only) and CD-RW discs (rewritable).
CD-Rs written during a multisession recording can be played, provided that the session has ended before the disc is played (depending on the write software).
However, depending on the condition of the CD-writer, computer and the disc used, you may find that not all discs will play. When playing a CD-R disc, it is normal for the unit to take up to 60 seconds to recognize the disc before starting to play.
If the disc is not recognized after a period of 120 seconds, remove the disc, and insert it again.
•Do not use its full capacity.
•CD-Rs should be preferably used instead of
CD-RWs (rewritable CDs) as, in certain cases, CD-RW playback may be faulty.
•Use reliable, good-quality CD write software.
•Close all other applications on the computer to ensure reliable CD-R disc recording.
Jpeg Files
CD-R and CD-RW with jpeg files. Certain jpeg files, including progressive jpeg files, cannot be read by this unit.
The total number of files and folders on the disc should be less than 650. Make sure that files have the “.jpg” extension. Files without the “.jpg” exten- sion will not be able to be read by the unit --- even thought the files are shown as jpeg images on your computer.
Additional Information
Sound Enhancement Systems
This receiver is equipped with several built-in sound enhancement systems.
Manufactured under license from Dolby Laboratories. ”Dolby” and the double-D symbol are trademarks of Dolby Laboratories.
Dolby Digital
The Dolby Digital mode lets you enjoy full digital surround from software processed in the Dolby Digital format. Dolby Digital provides better sound quality and a more powerful presence than conventional Dolby Surround. This unit is equipped with Dolby Digital 5.1 channel so that you can enjoy enhanced full digital surround sound. Different from Dolby ProLogic in that only four channels (Front Left, Front Right, Center and Rear) are used, the new system provides stereo separation of the rear speakers (Rear-Right, Rear- Left). Adding the subwoofer channel to the 5 channels for bass sounds (counted as 0.1 channel) results in 5.1 channels (or 6 Channels) that bring you the most sophisticated Dolby Digital sound enjoyment.
Technical Specifications:
Amplifier Section:
RMS Output Power: Dolby Digital Mode with 10% Total Harmonic Distortion
Rear Channels: 40 Watts/channel (1kH, 4Ω)
Front Channel: 40 Watts per channel (1kHz, 4Ω )
Center Channel: 40 Watts per channel (1kHz, 4Ω )
Subwoofer Channel: 50 Watts (100Hz, 3Ω) Total RMS Output Power, Dolby Digital mode: 250 Watts
Muting Attenuation: 70 dB
Frequency Response: 200Hz – 20KHz/3dB, 1KHz ref.
Subwoofer Frequency Response: 20Hz – 200Hz/- 3dB, 100Hz ref.
Signal to Noise Ratio: 70 dB (Dolby Digital)
AM Tuner Section:
Frequency Response: 2kHz +/-3dB, 400Hz ref.
Usable Sensitivity: 3000uV/m @ S/N 20dB
Signal to Noise: 38dB
IF Rejection: 35dB
FM Tuner Section:
Frequency Response: 15kHz +/-3dB, 1kHz ref.
Quieting: 24dB
Signal to Noise: 62dB(stereo) / 65dB(mono)
IF Rejection: 70dB
Dimensions (H x W x D mm) :
Unit: 67 x 430 x 243
Front Speakers: 112 x 88.8 x 90
Center Speaker: 112 x 88.8 x 90
Rear Speakers: 112 x 88.8 x 90
Subwoofer: 307 x 145 x 253
Limited Warranty
AVC MULTIMEDIA (“AVC”) makes the following limited warranty. This limited warranty extend to the original consumer purchaser and is limited to non-commercial use of the product.
One Year Parts & Labor Warranty
AVC products purchased in the United States or Canada are warranted to be free from defects in materials or workmanship for a period of one year from the date of their original retail purchase. If the unit fails to conform to this warranty, we will service the product using new or refurbished parts and products, at AVC’s sole discretion.
During a period of one year from the effective warranty date, AVC will provide, when needed, service labor to repair a manufacturing defect at its designated Service Center. To obtain warranty service in the United States or Canada, you must first call ourCustomer Support Center at 1-800-506-5746 or 1-877-252-6873, during the hours listed in the box below. The determination of service will be made by AVC Customer Support. PLEASE DO NOT RETURN YOUR UNIT TO AVC WITHOUT PRIOR AUTHORIZATION. New or remanufactured replacements for defective parts or products will be used for repairs by AVC at its designated Service Center for one year from the effective warranty date. Such replacement parts or products are warranted for an additional one year from the date of repair or replacement. The Customer will be required to ship the unit to the Service Center indicated at the time Customer Support is contacted to make the necessary repairs. The customer is responsible for all transportation charges to the service facility.
Packaging and Shipping Instruction
When you send the product to the AVC service facility you must use the original carton box and packing material or an equivalent as designated by AVC.
Your Responsibility
(1)You must retain the original sale receipt to provide proof of purchase.
(2)These warranties are effective only if the product is purchased and operated in the United States or Canada.
(3)Warranties extend only to defects in material or workmanship, and do not extend to any product or parts which have been lost or discarded, or damage to product or parts caused by misuse, accident, improper operation or maintenance, or use in violation of instructions provided with the product, or to product which has been altered or modified without authorization of AVC, or to products or parts thereof which have had the serial number removed or changed.
Limited Warranty
Out of Warranty
In the event your product requires repair after the limited warranty period has expired, please contact our Customer Support Center at 1-800-506-5746,1-877-252-6873 or
www.RCAav.com
Hours: Monday–Thursday: 9am–7pm, Friday: 9am–5pm, Saturday: 9am–NOON Eastern time.
Important:
You are responsible for any transportation, shipping or insurance relative to the return of product to our Product Returns Center.
All warranties implied by state law, including the implied warranties of merchantability and fitness for a particular purpose, are expressly limited to the duration of the limited warranties set forth above. With the exception of any warranties implied by state law as hereby limited, the foregoing warranty is exclusive and in lieu of all other warranties, guarantees, agreements and similar obligations of manufacturer or seller with respect to the repair or replacement of any parts. In no event shall AVC be liable for consequential or incidental damages.
No person, agent, distributor, dealer or company is authorized to change, modify or extend the terms of these warranties in any manner whatsoever. The time within action must be commenced to enforce any obligation of AVC arising under the warranty or under any statute, or law of the United States or Canada or any state thereof, is hereby limited to one year from the date of purchase. This limitation does not apply to implied warranties arising under state law.
This warranty gives you specific legal rights and you may also have other rights, which may vary, from state to state. Some states do not allow limitation on how long an implied warranty lasts, when an action may be brought, or the exclusion or limitation of incidental or consequential damages, so the above provisions may not apply to you.
For more information on other products and services, please visit our web site at
www.RCAav.com
Important: Also keep your “Bill of Sale” as proof of purchase.
Model no | Product name |
Type of set |
Serial no | Invoice no |
Date purchased | Dealer name |
FOR SERVICE AND REPAIR, PLEASE VISIT www.RCAav.com
Specifications and external appearance are subject to change without notice.
© 2009 AVC MULTIMEDIA
button to go to the next one, and the STOP or RETURN button to interrupt the slide show and display the disc’s contents.
English IB for RCA.indd 2
