Ricoh Aficio CL7200 Color Laser Printer

System Specifications

Main Unit CL7200 – Part # CL7200

Configuration:

Desktop

Technology:

Laser-beam scanning, electro-



photographic printing with dual-



component toner development,



four drums tandem method

Resolution:

True 1200 x 1200 dpi; 1200 x 600 dpi;



600 x 600 dpi

Printing Speed

Full-color: 28 ppm;

(@ 600 dpi):

Black & white: 32 ppm

First Print Speed:

Full-color: 12 seconds;



Black & white: 11 seconds

Dimensions (WxDxH):

CL7200: 22.7" x 26.7" x 26.7"



(575 x 678 x 745 mm)

Weight (Base Unit):

187 lb. (85 kg)

Warm-up Time:

Less than 95 seconds

Power Source:

120V, 60Hz

Power Consumption:

1320W or less

Energy Saver Mode:

19W or less

Paper Capacity:

Up to 3,100 sheets

CL7200 (base unit):

1,100 sheets (500 x 2, plus 100-



sheet Bypass Tray)

CL7200D (duplex):

1,100 sheets (500 x 2, plus 100-



sheet Bypass Tray)

CL7200DT1:

1,600 sheets (500 x 3, plus 100-



sheet Bypass Tray)

CL7200DT2:

2,100 sheets (500 x 4, plus 100-



sheet Bypass Tray)

CL7200DL:

3,100 sheets (500 x 2, plus 100-



sheet Bypass Tray, 2,000-sheet LCT)

Output Capacity

600 sheets/3,100 sheets

(Std/Max):



Paper Sizes (Max.):

Paper Trays/Optional Trays:



8.5" x 11", 8.5" x 14",



11" x 17", 7.5" x 10.5",



8" x 13", 8.25" x 13",



8.5" x 13", A5, A4, A3



Bypass Tray (PCL 5c/PCL 6/PS3



drivers): Width: 3.5" to 12" (90 to



148 mm);



Length: 5.8" to 18" (148 to 457 mm);



RPCS driver: Up to 49.6" (1,260 mm)

Paper Weights:

Paper Tray/Optional Tray:



Bond 16 – 28 lb. (60 – 105 g/m2);



Bypass Tray: Bond 16 – 45 lb. / 90 lb.



Index (60 – 163 g/m2);



LCT: 16 – 28 lb. Bond (60 – 105 g/m2)

Acceptable Paper Types: Plain paper, labels, transparencies,



envelopes, glossy paper, banner



paper, recycled paper

Safety Regulations:

UL1950/cUL; CSA No. 950; FDA-21;



CFR-J; FCC Class B

Controller Specifications

CPU:

Celeron 733MHz

Printer Languages:

Adobe®PostScript®3™, PCL 5c and



PCL 6 emulation, Ricoh RPCS



(Refined Printing Command Stream),



PDF Direct, and optional Camera



Direct Printing with PictBridge



compatible camera

Fonts:

PS 3: 136 Type 1 fonts; PCL:



45 fonts (TrueType: 10 fonts,



Intellifonts: 35 fonts)

Memory:

256MB RAM standard; Up to 512MB



RAM maximum (1 free slot)

Standard Interfaces:

10/100BaseTX Ethernet, USB 2.0

Optional Interfaces*

IEEE 802.11b Wireless LAN,



Bluetooth Wireless, IEEE 1284 Parallel,



IEEE 1394,Gigabit Ethernet, USB Host



*Only one additional interface can be



installed.

Network Protocols:

TCP/IP, Novell IPX/SPX, SMB (NetBEUI,



Net BIOS over TCP/IP), AppleTalk

Drivers:

RPCS, PCL 5c/6, and PS: Windows



95/98SE/Me/NT 4.0/2000/XP/Server



2003;



PS: Macintosh 8.6 or later, OS X



(v.10.1, 10.2, 10.3);



UNIX: Solaris, HP-UX, Red Hat Linux,



SCO

Print Utilities:

SmartDeviceMonitor for



Administrator and Client, Printer



Utility for Mac, DeskTopBinder V2



Lite, Font Manager 2000

Controller Options

40 GB Hard-disk Drive

Part # 402089

IEEE 1394

Interface Board Type B *

Part # 411264

IEEE 1284

Interface Board Type A*

Part # 411699

IEEE 802.11b Wireless LAN Interface

Part # 402378

Type H*





Bluetooth Interface Board Type 3245*

Part # 412178

USB Host Interface*

Part # 402304

Gigabit Ethernet Interface Board*

Part # 402302

*Only one additional interface can be installed.

User Account Enhance Unit Type E – Part # 402270; Monitors printer usage and restricts users’ access via Web Image Monitor and SmartDeviceMonitor. 30 user codes ship standard. This option provides for a total of 500 user codes. Direct Camera Print Card Module (SD Card) –

Part # 402361; Enables direct printing from a PictBridge enabled digital camera, without a PC (requires optional USB Host Interface Part # 402304).

Memory Options

144-pin DIMM SD-RAM (PC133 compliant); Maximum of 512MB

64MB SDRAM Type C

Part # 001178MIU

128MB SDRAM Type C

Part # 001179MIU

256MB SDRAM Type C

Part # 001180MIU

Paper Handling Accessories

1 x 500-sheet Paper Feed Unit

Part # 402431

2 x 500-sheet Paper Feed Unit

Part # 402432

2,000-sheet Large-capacity Tray

Part # 402433

Stand FAC28

Part # 402373

Duplex Unit

Part # 402088

Booklet Finisher SR950 Part # 412143

Paper Size:

8.5" x 11" to 11" x 17"

Paper Weight:

16 – 34 lb. Bond (60 – 128g/m2)

Stack Capacity:

Sort: 1,000 sheets (8.5" x 11");



500 sheets (8.5" x 14" or larger)



Staple: 1,000 sheets or 30 sets



(8.5" x 11"); 500 sheets or 30 sets



(8.5" x 14"or larger)



Folding: 1 set = 6 – 10 sheets: 10



sets; 1 set = 2 – 5 sheets: 20 sets

Staple Paper Size:

8.5" x 11" to 11" x 17"

Staple Paper Weight:

17 – 21 lb. Bond (64 – 80 g/m2)

Staple Capacity:

50 sheets (8.5" x 11"); 25 sheets



(8.5" x 14" or larger)

Staple Positions:

Normal Staple (Top, Bottom, Left 2),



Saddle Stitch

Hole Punch:

Available as option for SR950



Part # 411585

Number of Holes:

2 or 3, switchable

Sheet Finisher SR960 Part # 412139

Number of Trays:

2

Upper Tray:

Paper Size: 8.5" x 11" to 11" x 17";



Paper Weight: 16 – 28 lb. Bond



(60 – 105 g/m2)



Stack Capacity: 500 sheets 8.5" x 11";



250 sheets 8.5" x 14" or larger

Lower Tray:

Paper Size: 8.5" x 11" to 11" x 17";



Paper Weight: 16 – 28 lb. Bond



(60 – 105 g/m2);



Stack Capacity: 2,000 sheets



8.5" x 11"; 750 sheets 8.5" x 14"



or larger

Staple Paper Size:

8.5" x 11" to 11" x 17"

Staple Paper Weight:

17 – 24 lb. Bond (64 – 90 g/m2)

Staple Capacity:

50 sheets (8.5" x 11"); 30 sheets



(8.5" x 14" or larger, mixed-size sets)

Staple Positions:

Upper Left and Upper Right:



1 staple diagonal; Upper Left and



Upper Right: 1 staple horizontal;



Left, Top, Right margins: 2 staples

Hole Punch:

Available as option for SR960



Part # 410785

Number of Holes:

2 or 3, switchable

Punch Positions:

Top, Left, Right margins

Notes:



1.Only one of 500 x 1, 500 x 2, 2,000-sheet Large-capacity Tray or Stand can be installed.

2.Sheet Finisher or Booklet Finisher requires a duplex unit and a minimum 1,600 sheet paper capacity.

3.Sheet Finisher and Booklet Finisher cannot be installed simultaneously.

4.Both Finishing units can be configured with an optional hole punch.

IS300e Image Scanner (MFP Upgrade Option) Part # IS300e

Scanning Functionality Scan-to-Email; Scan-to-Folder

FTP/SMB, Network TWAIN scanning,

Scan-to-Print

IS300e Image Scanner Table for Aficio 7200 Color Printer

It is recommended that the IS300e scanner table is sold only with the DT1, DT2, or DL configurations. The stand is adjustable and can accommodate the different heights. The stand can not be used with the CL7200 base model (with duplex option) and CL7200D version. You must purchase a minimum of 1 additional paper tray in order for these units to accommodate the scanner table.

Consumables*

Color LP Toner Cartridge





(Black) Yield:

24,000 pages @ 5%

Part # 888442

Color LP Toner Cartridge





(Yellow) Yield:

10,000 pages @ 5%

Part # 888443

Color LP Toner Cartridge





(Magenta) Yield:

10,000 pages @ 5%

Part # 888444

Color LP Toner Cartridge





(Cyan) Yield:

10,000 pages @ 5%

Part # 888445

Black Image Drum Yield:

40,000 pages

Part # 402310

Color Image Drum Yield:

40,000 pages

Part # 402305

Development Unit





(Black) Yield:

80,000 pages

Part # 402308

Development Unit





(Color) Yield:

80,000 pages

Part # 402306

Fusing Unit Yield:

80,000 pages

Part # 402307

Waste Toner Bottle Yield:

40,000 pages

Part # 400662

Staple Cartridge for SR960 5,000 shots

Part # 410801

Refills for SR960 Staple





Cartridge

5,000 x 3 shots

Part # 410802

Staple Cartridge +1 refill





for SR950

5,000 shots

Part # 411730

*CL7200 ships with starter toner cartridges at 12,000 pages for black toner and 5,000 pages for color toner @ 5% coverage; all other consumables ship at full yield.

Specifications subject to change without notice.

www.ricoh-usa.com

Ricoh Americas Corporation, Five Dedrick Place, West Caldwell, NJ 07006

Ricoh® and the Ricoh Logo are registered trademarks of Ricoh Company, Ltd. Windows® and Windows® 95/98/Me/NT4.0/2000/XP are registered trademarks of Microsoft Corporation. Macintosh®, Mac® OS and AppleTalk® are registered trademarks of Apple Computer, Inc. Adobe® and PostScript® are registered trademarks of Adobe Systems, Inc. PCL® is a registered trademark of Hewlett-Packard Company. All other trademarks are the property of their respective owners. Printed in U.S.A. on recycled paper. Print speed may be affected by network, application or PC performance. Specifications and external appearances are subject to change without notice. Products are shown with optional features.

PA-0599

Printed in U.S.A. on recycled paper because Ricoh cares.
