General
General
Model Name	SyncMaster 913N
LCD Panel
Size	19" Diagonal (48 cm)
Display area	376.32 mm (H) x 301.056 mm (V)
Pixel Pitch	0.294 mm (H) x 0.294 mm (V)
Type	a-si TFT active matrix
Synchronization
Horizontal	30 ~ 81 kHz
Vertical	56 ~ 75 Hz
Display Color
16,2M Colors
Resolution
Optimum resolution	1280 x 1024@60 Hz
Maximum resolution	1280 x 1024@75 Hz
Input Signal, Terminated

RGB Analog 0,7Vp-p Positive at 75Ω

Separate H/V sync, Composite sync, SOG, TTL level positive or negative.

Maximum Pixel Clock

140 MHz

Power Supply

AC 100 ~ 240 VAC(+/- 10%) , 60/50 Hz ± 3Hz

Signal Cable

15pin-to-15pin D-sub cable, detachable

Power Consumption
