Phone layout

Install the SIM card and battery

1. Remove the battery cover and insert the SIM card.

Instructional icons

1

4

5

26 3

7

8

1

4-way navigation key

In ldle mode, access user- defined menus, make a fake call (down); In Menu mode, scroll through menu options Depending on your service provider, pre-defined menus may differ

See "Make fake calls"

2

Dial key

Make or answer a call; In Idle mode, retrieve recently dialled, missed, or received numbers

3

Voice mail service key In ldle mode, access voice mails (press and hold)

4

Softkeys

Perform actions indicated at the bottom of the display

5

Confirm key

In Idle mode, access Menu mode; In Menu mode, select the highlighted menu option or confirm an input Depending on your service provider or region, the key may perform differently

6

Power/Menu exit key

Turn the phone on and off (press and hold); End a call; In Menu mode, cancel input and return to Idle mode

7

Alphanumeric keys

8

Silent profile key

In ldle mode, activate or deactivate the silent profile (press and hold)

Your phone displays the following status indicators on the top of the screen:

Icon

Description



Signal strength









Call in progress







Call diverting activated







Roaming (outside of normal service area)







Alarm activated







New text message (SMS)







New voice mail message







Normal profile activated







Silent profile activated







Battery power level





Battery cover

SIM card



2. Insert the battery and replace the battery cover.

Battery

Charge the battery

1. Plug the supplied travel

2. When charging is

adapter.

finished, unplug the



travel adapter.

To AC power outlet

Do not remove the battery from the phone before unplugging the travel adapter first. Otherwise, the phone may be damaged.

Note: notes, usage tips, or additional information

Followed by: the order of options or menus you

must select to perform a step; for example: In Menu

mode, select Messages Create new message (represents Messages, followed by Create new message)

[ ]

Square brackets: phone keys; for example: [

]

(represents the Power/Menu exit key)







Angled brackets: softkeys that control different

<> functions at each screen; for example: <OK> (represents the OK softkey)

Turn your phone on or off

To turn your phone on,

1.Press and hold [].

2.Enter your PIN and press <OK> (if necessary).

3.Set the time and date and press <Save> (if necessary)

To turn your phone off, repeat step 1 above.

If you remove the battery, the time and date will be reset.

Access menus

To access your phone's menus,

1. In Idle mode, press <Menu> to access Menu mode.

You may need to press the Confirm key to access Menu mode depending on your region or service provider.

2.Use the Navigation key to scroll to a menu or option.

3.Press <Select>, <Save>, or the Confirm key to confirm the highlighted option.

4.Press <Back> to move up one level; Press [] to return to Idle mode.

When you access a menu requiring the PIN2, you must enter the PIN2 supplied with the SIM card. For details, contact your service provider.

Samsung is not responsible for any loss of passwords or private information or other damages caused by illegal software.

Make a call

1.In Idle mode, enter an area code and a phone number.

2.Press [] to dial the number.

3.To end the call, press [].

Answer a call

1.

When a call comes in, press [ ].

2.

To end the call, press [

].

Adjust the volume

To adjust the volume of the ringtone

1.In Menu mode, select Settings Profiles.

2.Scroll to the phone profile you are using.

If you are using the silent or offline profile, you are not allowed to adjust the volume of the ringtone.

3.Press <Options> → Edit Volume.

4.Scroll left or right to adjust the volume level.

5.Press <Save>.

To adjust the volume of voice during a call

While a call is in progress, press the Navigation key up or down to adjust the volume.

In noisy environments, you may have difficulty hearing the calls while using the speakerphone feature. For better audio performance, use the normal phone mode.

Change your ringtone

1.In Menu mode, select Settings Profiles.

2.Scroll to the profile you are using.

If you are using the silent or offline profile, you are not allowed to change the ringtone.

3.Press <Options> → Edit Call ringtone.

4.Select a ringtone.

To switch to another profile, select it from the list.

Call a recently dialled number

1.In Idle mode, press [].

2.Scroll left or right to a call type.

3.Scroll up or down to a number or name.

4.Press the Confirm key to view details of the call or

[] to dial the number.

Enter text



To change the text input mode



Press and hold [

] to switch between T9 and ABC



modes.







Press [

] to change case or switch to Number mode.

Press [

] to switch to Symbol mode.

Press and hold [

] to select an input mode or change



the input language.

T9 mode

1.Press appropriate alphanumeric keys to enter an entire word.

2.When the word displays correctly, press [0] to insert a space. If the correct word does not display, press the Navigation key up or down to select an alternate word.

ABC mode

Press an appropriate alphanumeric key until the character you want appears on the display.

Number mode

Press an appropriate alphanumeric key to enter a number.

Symbol mode

Press an appropriate alphanumeric key to enter a symbol.

To move the cursor, press the Navigation key.

To delete characters one by one, press <Clear>. To delete all of the characters, press and hold <Clear>.

To insert a space between characters, press [0].

To enter punctuation marks, press [1].

Add a new contact

The memory location to save new contacts may be preset depending on your service provider. To change the memory location, in Menu mode, select Phonebook

Management Save new contact to → a memory location.

1.In Idle mode, enter a phone number and press <Options>.

2.Select Create contact → a memory location (phone or SIM).

3.Select a number type (if necessary).

4.Enter contact information.

5.Press the Confirm key to add the contact to memory.

Send and view messages

To send a text message

1.In Menu mode, select Messages Create new message.

2.Enter a recipient number and scroll down.

3.Enter your message text. See "Enter text."

4.Press the Confirm key to send the message.

To view text messages

1.In Menu mode, select Messages Inbox.

2.Select a text message.

Make fake calls

You can simulate an incoming call when you want to get out of meetings or unwanted conversations.

To make a fake call

In Idle mode, press and hold the Navigation key down.

Activate the mobile tracker

When someone inserts a new SIM card in your phone, the mobile tracker feature will automatically send the contact number to two recipients to help you locate and recover your phone. To activate the mobile tracker,

1.In Menu mode, select Settings Security Mobile tracker.

2.Enter your phone password and press <OK>.

3.Select Settings.

4.Enter your Mobile tracker password and press <OK>.

The first time you access Mobile tracker, you will be prompted to create and confirm a password.

5.Scroll left or right to On.

6.Scroll down and press the Confirm key to open the recipient list.

7.Press the Confirm key to open your contact list.

8.Select a contact.

9.Select a number (if necessary).

10.When you are finished selecting contacts, press

<Options> → Save.

11.Scroll down and enter the sender's name.

12.Press <Options> → Save → <Accept>.

To change the password for the Mobile tracker, select

Change Mobile tracker password.

Set and use alarms

To set a new alarm

1.In Menu mode, select Alarms.

2.Select an empty alarm location.

3.Set alarm details.

4.Press <Save>, or press <Options> → Save.

To stop an alarm

When the alarm sounds,

Press <OK> or the Confirm key to stop the alarm.

Press <Snooze> to silence the alarm for the snooze period.

To deactivate an alarm

1.In Menu mode, select Alarms.

2.Select the alarm you want to deactivate.

3.Scroll left or right to Off.

4.Press <Save>.

If the battery has been removed, the scheduled alarm may not sound.

Manage your calendar

Create an event

1.In Menu mode, select Calendar.

2.Press <Options> → Create → an event type.

3.Enter the details of the event as required.

4.Press <Save>, or press <Options> → Save.

View events

1.In Menu mode, select Calendar.

2.Select a date on the calendar.

3.Select an event to view its details.



Declaration of Conformity (R&TTE)

We,

Samsung Electronics

declare under our sole responsibility that the product

GSM Mobile Phone : GT-E1151

to which this declaration relates, is in conformity with the following standards and/or other normative documents.

SAFETYEN60950-1:2001+A11:2004

EMCEN301489-01V1.8.1(04-2008) EN301489-07V1.3.1(11-2005)

SAREN50360:2001

EN62209-1:2006

RADIOEN301511V9.0.2(03-2003)

We hereby declare that [all essential radio test suites have been carried out and that] the above named product is in conformity to all the essential requirements of Directive 1999/5/EC.

The conformity assessment procedure referred to in Article 10 and detailed in Annex[IV] of Directive 1999/5/EC has been followed with the involvement of the following Notified Body(ies):

BABT, Forsyth House, Churchfield Road, Walton-on-Thames, Surrey, KT12 2TD, UK* Identification mark: 0168

The technical documentation kept at :

Samsung Electronics QA Lab.

which will be made available upon request.

(Representative in the EU)

Samsung Electronics Euro QA Lab.

Blackbushe Business Park, Saxony Way,

Yateley, Hampshire, GU46 6GG, UK*

2010.03.05

Yong-SangPark/S.Manager

(place and date of issue)

(name and signature of authorised person)

*It is not the address of Samsung Service Centre. For the address or the phone number of Samsung Service Centre, see the warranty card or contact the retailer where you purchased your phone.
