配置 尺寸

PIP/PBP

PIP/PBP 模式

尺寸

位置

声源

信号源

图像尺寸

对比度

75/75

--显示的图像可能因型号而异。

选择子屏幕的大 小和宽高比。

居左: HDMI 1

居右: HDMI 2

返回

选择子屏幕的尺寸和纵横比。

1 当功能键导引出现时,向上移动 JOG 按钮以选择 。然后按 JOG 按钮。

2 /控制 JOG 按钮移至 PIP/PBP,然后按下 JOG 按钮。

3 /控制 JOG 按钮移至 尺寸,然后按下 JOG 按钮。

•• :如果要在左右两侧屏幕最佳分辨率为 1280 x 1080(宽 x 高)时使用 PBP 模式,请选

择此图标图像。

•• :如果要在子屏幕最佳分辨率为 720 x 480(宽 x 高)时使用 PIP 模式,请选择此图标

图像。

•• :如果要在子屏幕最佳分辨率为 960 x 540(宽 x 高)时使用 PIP 模式,请选择此图标

图像。

•• :如果要在子屏幕最佳分辨率为 1280 x 540(宽 x 高)时使用 PIP 模式,请选择此图标 图像。

4 /控制 JOG 按钮移至所需的选项,然后按下 JOG 按钮。

5 将应用选定选项。

43

Page 43
Image 43
Samsung LS29E790CNS/EN manual 配置 尺寸

LS29E790CNS/EN specifications

The Samsung LS29E790CNS/EN is a sophisticated ultra-wide monitor designed for diverse usage scenarios, from professional workstations to immersive entertainment. With a 29-inch screen that features a 21:9 aspect ratio, this monitor transforms multitasking and enhances productivity by providing ample screen real estate.

One of the standout features of the LS29E790CNS/EN is its high-resolution display. Offering a resolution of 2560 x 1080 pixels, this monitor provides stunning clarity, allowing users to view detailed images and crisp text. Whether you are editing photos, creating designs, or working on spreadsheets, the ultra-wide format enables efficient side-by-side multitasking that improves workflow.

The LS29E790CNS/EN utilizes advanced PLS (Plane-to-Line Switching) technology, which enhances the display's color reproduction and viewing angles. This means that the monitor delivers vibrant colors and consistent brightness, even when viewed from extreme angles. Users can enjoy stunning visuals whether they are sitting in front of the monitor or sharing content with others nearby.

Another noteworthy aspect is its impressive color accuracy, with support for 100% sRGB coverage. This makes it an ideal choice for graphic designers, photographers, and video editors who require precise color representation in their work. The monitor also features Samsung's Picture-by-Picture (PBP) functionality, allowing users to connect and view content from multiple sources simultaneously. This is particularly beneficial for users who may want to keep an eye on a reference image or video while working on their primary display task.

In terms of connectivity, the LS29E790CNS/EN includes multiple ports, such as HDMI and DisplayPort, ensuring compatibility with a range of devices from computers to gaming consoles. Furthermore, it is equipped with built-in speakers, which enhance the multimedia experience for casual viewers and gamers.

Device ergonomics are also considered in the design of this monitor. With adjustable height, tilt, and swivel options, users can customize their viewing experience for maximum comfort. This flexibility is essential for long working hours, helping to reduce fatigue and improve productivity.

In summary, the Samsung LS29E790CNS/EN is a versatile ultra-wide monitor that combines advanced display technologies with practical features, making it an excellent choice for both work and entertainment. Whether you are enhancing your productivity at the office or enjoying immersive media at home, this monitor is engineered to elevate your visual experience.
