SMC Networks manual EZ ConnectTM, Mbps Wireless USB Adapter, Model Number SMC2662W, Overview

	EZ ConnectTM
wireless
	11 Mbps Wireless USB Adapter
		Model Number::	SMC2662W

This wireless USB adapter combines the ease-of-use and convenience of USB-enabled PCs with the bene- fits of 11 Mbps wireless operation in a full-featured solution for the networked environment. It connects instantly with an existing Ethernet installation to sup- port mobile users, temporary work sites, sharing of peripherals, and wireless multimedia.

Wireless solutions provide the ultimate in mobility, simple and flexible installation options, a reduced cost of ownership (no cabling costs or maintenance), and excellent scalability in supporting additional PCs on the LAN. 11 Mbps wireless LAN solutions are ideal for use with cable or xDSL modems and SOHO applica- tions.

In the typical wireless configuration, an Access Point (SMC2655W) connects to a wired network.The Access Point supports up to 64 users, with a maximum range of 1,800 feet. Users access the LAN via SMC wireless adapters in their notebooks or desktops. The wireless LAN adapters interface between the client Network Operating System and the Access Point. In a peer-to- peer configuration, one wireless card is needed for each computer, but no Access Point is required.

6H u g h e s Irvine, CA 92618 1-800-SMC-4YOU w w w. s m c. co m

Overview

Features

•Wireless connectivity via USB por t

•Up to 11 Mbps wireless LAN

•Up to 1,800 ft. operating range

•2.4 GHz frequency band

•Direct Sequence Spread Spectrum (DSSS)

•64-bit or 128-bit encryption

Benefits

•Instant access to shared information without the need to plug in

•Network managers can set up, move, or expand a new LAN with no need for installation or moving wires

•11 Mbps performance will meet most foreseeable networking needs

•Wireless LANs are tremendously conven- ient, help to enhance productivity, and provide a real cost benefit o ver traditional wired networks (no installation or mainen- nance expenses)

•Plug-and-play; no configuration needed

Compatibility

•IEEE 802.11b

•Windows 98/Me/2000
