Quick

Installation Guide

SMCWAPS-G

EZ Connect™g

802.11g 54 Mbps Wireless

Network Storage Adapter

English:

Quick Installation Guide

German:

Installationskurzanleitung

Spanish:

Guía de inicio rápido

French:

Guide d’installation rapide

Dutch:

Beknopte installatiehandleiding

Portuguese: Manual de Instalação rápida

Swedish: Snabbinstallationshandbok

SMCWAPS-G

Q1

English:

Install the Software from the installation CD-ROM.

German:

Installieren Sie die Software von der Installations-CD-ROM.

Spanish:

Instale el software del CD-ROM de instalación.

French:

Installez le logiciel à partir du CD-ROM d'installation.

Dutch:

Installeer de software vanaf de CD-ROM.

Portuguese:

Instale o software desde o CD-Rom de instalação.

Swedish:

Installera programmet från installations-cd:n.

English:

Attach a harddrive or external storage device to the AP. Then connect the AP by wire to the network where a DHCP server is present.

German:

Schliessen Sie ein Laufwerk oder ein externes Speichergerät an den AP (Access Point) an. Verbinden Sie dann den AP per Kabel dort mit dem Netzwerk, wo sich ein DHCP Server befindet.

Spanish:

Conecte un disco duro o dispositivo externo de almace- namiento al punto de acceso. A continuación conecte el punto de acceso a la red por cable. Asegúrese de tener un servidor DHCP en la red.

French:

Connectez un périphérique de stockage, de type disque dur de 2,5'' ou externe, au point d'accès. Puis connectez le point d'accès au réseau avec un câble Ethernet et celui-ci recevra alors une adresse IP de votre serveur DHCP.

Dutch:

Installeer een interne harde schijf of sluit een externe harde schijf aan op de AP. Sluit de AP op basis van ethernet aan op een bestaand LAN netwerk met een reeds aanwezige DHCP server.

Portuguese:

Ligue um disco rigído ou um produto de armazenamento externo ao AP. Ligue o AP por cabo á sua rede onde tem o servidor DHCP activo.

Swedish:

Anslut en hårddisk eller extern lagringsenhet till accesspunk- ten. Anslut sedan accesspunkten via kabel till det nätverk där

Qen DHCP-server finns.

2

Q3

English:

Plug in your power adapter. Power requirements are: 110-240V, 50/60Hz. Input power: 5VDC, 3A

German:

Stecken Sie Ihren Stromanschluß an. Stromanforderungen sind: 110-240V, 50/60Hz. Input power: 5VDC, 3A

Spanish:

Conecte su fuente de alimentación. Los requisitos de alimentación son: 110-240V, 50/60HZ. Alimentación de entrada: 5VDC, 3A

French:

Branchez l'alimentation électrique . Alimentations requises du transformateur: 110-240V, 50/60Hz. Alimentation du produit: 5VDC, 3A

Dutch:

Sluit nu de voeding (110-240V, 50/60Hz. Input 5VDC, 3A) aan op de AP.

Portuguese:

Ligue o seu transformador de corrente. Os caracteristicas devem ser: 110-240V, 50/60Hz. Input power: 5VDC, 3A

Swedish:

Anslut nätadaptern. Strömförsörjningskrav: 110–240 V,

50/60 Hz. Ineffekt: 5 V likström, 3 A

English:

Run the installation wizard to set up the AP Storage from the Windows' Start Menu.

German:

Lassen Sie den Installations-Wizard laufen, um den AP Speicher von dem Windows Start Menü heraus einzurichten.

Spanish:

Desde el menú de inicio de Windows active el asistente de instalación para configurar el dispositivo de almacenamiento del punto de acceso.

French:

Lancez "installation wizard" pour installer le point d'accès/serveur de stockage à partir du menu de démarrage Windows.

Dutch:

Gebruik de wizard (Windows Start Menu) om de AP te configureren.

Portuguese:

Corra o utilitário de instalação para configurar o AP Storage através do menu de Inicio do Windows.

Swedish:

Kör installationsguiden för att göra inställningar för accesspunktslagring från startmenyn i Windows.

Q4
