Drive System-Self-Propelled

Item

Part No

Qty

Description

Note

36

7032831



CONNECTOR, Transfer Rod

Was 31874

37





ASSEMBLY, Drive-Disc

NOTE: Order Kit #6-0710 for









replacement.

38





BUSHING

NOTE: Order Kit #6-0710 for









replacement.

39

7029025

2

SPRING (Wheel Drive & Idler)

Was 13694

40

7032116



ARM, Idler



41

7013847



RETAINER, 3/8 Bolt



42

7090078



BOLT, 1/4-20 x 1-1/4" Carriage



43

7090372



NUT, 1/4-20 Hex Center Lock





7050751



ASSEMBLY, Deck Bracket

(Includes items 44 thru 46)

44

7033774



BRACKET, Deck

Was 31919 (Now 17696 +









33774)

45

7012306

2

BUSHING, Flange



46

7021758



SPACER



47

7090534



SCREW, 5/16-18 x 1/2" Hex Head Cap



48

7090391



WASHER, 5/16 Internal Tooth Lock



49

7011079



WASHER, Spring



50

7091597



COTTER-PIN, 3/32 x 1/2"

Was 90555

51

7091122



SCREW, 1/4-20 x 1/2" Self-Tapping

Was 90539

52

7090731

2

BOLT, 5/16-18 x 5/8" Short Neck Carriage



53

7091601

2

NUT,5/16-18 Hex Flange Lock

Was 90585

54

7012122



SPRING, Clutch



55

7015752



LINK, Transfer ('89 Models & Later)



56

7015753



JOINT, Ball ('89 Models & Later)



57

7090095



NUT,1/4-28 Hex('89 Models & Later)



58

7091294



WASHER, 1/4 Flat ('89 Models & Later)

Was 90055

59

7090053



WASHER, 1/4 internal Tooth Lock ('89 Models & Later)



Footnotes:

21" STEEL DECK WALK MOWERS



Manual No. 7006041

SERIES 1 & 5

23

TP 400-5124-3-WB-N

Page 23
Image 23
