LWS16/LWS17

LWS44

Commercial Quality

Built tough to stay that way. The No. 1 supplier of commercial coin-operated laundry equip- ment, Speed Queen continues to lead in customer satisfaction. Speed Queen homestyle washers and dryers are U.S. Department of Energy compliantto 2007 washer standards for energy and water savings.They also feature many of the same rugged, reliable parts found in the coin-operated machines, so they’re built to last.

Quality Washer

Components

Long-lasting galvanized steel cabinet.

Dependable Eversmooth transmission.

Heavy-duty,1/2 HP,two-speed motor.

Single-belt drive simplicity.

Corrosion-resistant polypropylene pump.

Pump clips for service convenience.

Unit is 100% front serviceable.

Eight cycles; three temperatures.

. Adjustable water level control.

Flex vane agitator with fabric softener dispenser.

Bleach dispenser.

www.speedqueen.com

AutomaticBalanceSystem

Residents will appreciate the Automatic Balance System (ABS) for smooth and quiet operation, even on wood floors.The ABS provides the industry’s best out-of-balance handling, completing wash cycles without interruption.

Multi-Cycle and TemperatureControls

Speed Queen offers you a user-friendly free-wheeling timer knob for start and cycle selections with energy saver designation.

PolyTuff® Agitator

High vanes and extra long 210º agitation stroke deliver superior washability for all load sizes.

Extra-Large Stainless Steel Washtub

Our durable stainlesssteel washtub becomes smoother with each use so clothes are less likely to snag (Available on LWS17 and LWS44 only).

Attractive Control Panel

Commercial homestyle topload washers have attractive styling to match electric or gas dryers.

Washer Specifications



LWS16/LWS17,LWS44

BasketVolume -

3.3 (95)







cu. ft. (liters)









Width - in (mm)

25 5/8" (651)







Depth - in (mm)

28" (711)







Height* - in (mm)

43" (1092)







WorkSurfaceHeight -

36" (914)







in (mm)









Weight - lb (kg)

180 (82)







ShippingWeight- lb(kg)

195 (88)







CycleTime

27 minutes



Motor HP

Variable Speed Induction, 1/2 HP

Water Consumption

36.7







gal. per cycle



















Water Factor -

11.0







gal. per cu.ft.









ModifiedEnergyFactor

1.27







HotWaterUsage -

5.33







gal. per cycle









Water Pressure -

20 to 120 (1.4/8.3)



psi (bar)



















Spin Speed - RPM

710/473







Cycle/Temperature

Regular





Hot





Permanent Press





Warm



Delicate





Cold











ElectricalSpecifications

120/60/1-15 amp



Agency Approval

UL



Activation

Pull-to-Start



Self-AdjustingRearLegs

Yes



Top and Lid Finish

Powder Paint



Colors

White



* Heights may vary slightly depending on leveling adjustments.

Motor: 1/2 HP reversing, permanently lubricated. Electrical

Requirements: Grounded 3-wire, 120V, 60 Hz AC, 15 amp circuit separately fused.

At Speed Queen, we’re so confident that our heavy-duty commercial washers and dryers are Commercial Built to Last Longer, that we’re offering the following limited warranty to prove it: Through three years† — Any part of the washer, dryer or stack dryer. Through five years† — The washer transmission assembly, base and cabinet assembly including top, lid and door, against rust from inside out. Lifetime† — The stainless steel washtub.

Parts only. Labor not included. See Speed Queen Warranty Bond for specifics.

Due to continuous produ ct improvements, design and specifications subject to change without notice. The quality management systems at Alliance Laundry Systems manufacturing facilities are registered as ISO 9001:2000 compliant. Features and certifications may vary by model.

©Copyright 2007 Alliance Laundry Systems LLC

AM07-209
