Qosmio – impressive entertainment and computing.

Immersive video graphics

At the heart of the product is the QosmioEngine, a superlative video processor delivering a high-quality visual experience for TV, 3D gaming, viewing multimedia content, DVD movies and more.

Qosmio G20

17-inch widescreen display

Images are brought to life

The Toshiba TruBrite display delivers vivid images like you’ve never seen before. The Qosmio F20 with a brightness of 450 cd/m2 and the Qosmio G20 with 480 cd/m2 will astound you with great colour depth, wide viewing angles and anti-glare technology to deflect outside light.

Simplicity comes from intuitive design

Qosmio also delivers on the promise of simplicity with its QosmioPlayer. This intuitive graphical interface bypasses the Windows® operating system when booting to offer quick and easy TV

and digital entertainment at the touch of a button.

The thrill of mobile High

Definition viewing

Thanks to “HD to go” from Toshiba, High Definition viewing is now going mobile. Experience WMV HD content so vibrant it almost seems alive. “HD to go”, Toshiba’s

innovative combination of powerful performance advanced graphics and outstanding widescreen technology, delivers the ultimate thrill of mobile High Definition viewing.



headphone, i.LINK® (IEEE1394),

RJ-45, i.LINK® (IEEE1394), built-in microphone,

trademarksAllcountries.otherand/orStatesUnitedare acknowledged. Productspecifications,

thosefromvarymayandnoticewithoutchangeto shown. Errors and omissionsexcepted.

Model

Qosmio F20-155

Qosmio G20-141





Processor /

Intel® Centrino® mobile technology including

Intel® Centrino® mobile technology including





Technology

Intel® Pentium® M processor 770 (2.13 GHz,

Intel® Pentium® processor 780 (2.26 GHz,







533 MHz Front Side Bus, 2 MB 2nd level cache),

533 MHz Front Side Bus, 2 MB 2nd level cache),







Intel® PRO/Wireless 2200BG network connection

Intel® PRO/Wireless 2200BG network connection







and Intel® 915 PM Express chipset

and Intel® 915 PM Express chipset





Operating system

Microsoft® Windows® XP Media Center Edition





Display

15.4” Toshiba TruBrite WXGA TFT display,

17” Toshiba TruBrite WXGA+ TFT display,







resolution: 1,280 x 800, brightness: 450 cd/m2

resolution: 1,440 x 900, brightness: 480 cd/m2





Hard disk

100 GB ( 5,400 rpm) Serial ATA

200 (100 + 100) GB (5,400 rpm) Serial ATA





System memory

1,024 (512 + 512) MB, maximum expandability: 2,048 MB, technology: DDR2 RAM





Optical device

DVD Super Multi (Double Layer) drive













Graphics adapter

NVIDIA® GeForce™ Go 6600, 128 MB DDR SDRAM













TV tuner

Built-in hybrid analogue and digital (DVB-T) TV Tuner













Pointing device

Touch Pad















Wired & wireless

Ethernet LAN, international V.90 modem (V.92 ready),

Ethernet LAN, international V.90 modem (V.92 ready),





communication

Wireless LAN (802.11b/g)

Wireless LAN (802.11b/g), Bluetooth™ 1.2















Sound system

Toshiba Bass Enhanced Sound System with SRS® TruSurround XT™ System and SRS® WOW™,







built-in Harman Kardon® stereo speakers, volume dial















Interfaces

DC-in, external microphone, external monitor,

DC-in , headphone, external monitor, RJ-11,







Monitor-in (Line-in), RJ-11, RJ-45, S-Video-in

built-in speaker, 4x USB 2.0, S/PDIF (Headphone),

inCorporationMicrosoftoftrademarksortrademarksthe

subjectarecoloursandspecificationsdesignProduct



(Composite/Line-in), S-Video-out, S/PDIF

Monitor-in (line-in port), TV-antenna,



(Headphone), built-in speaker, 3x USB 2.0,

S-Video-in (Composite/Line-in), Dolby AC3 digital,







Dolby AC3 digital, D-Video out

TV-out (s-video, Component-out)















Expansion

5-in-1 Bridge Media Slot,

5-in-1 Bridge Media slot,







PC Card slot for 1x Type II card,

PC Card slot for 1x Type II card,







2x memory slots

2x memory slots, Express Card™ slot















Battery

Main, technology: lithium-ion,

Main, technology: lithium-ion,







maximum life: up to 2:35 (Mobile Mark™) hours

maximum life: up to 2:15 (Mobile Mark™) hours















Bundled software

InterVideo® WinDVD Creator 2 Platinum,

InterVideo® WinDVD Creator 2 Platinum,







Microsoft® Office OneNote™ 2003*,

InterVideo’s WinDVR® 5, Microsoft® Office







online user manual, Sonic™ Record Now!,

OneNote™ 2003, online user manual,







SRS® TruSurround XT™ technology for

WinDVD™, Sonic™ Record Now!, SRS® TruSurround







virtual surround sound, Toshiba ConfigFree™,

XT™ technology for virtual surround sound,







Toshiba utilities and drivers, Windows

Toshiba ConfigFree™, Toshiba utilities and drivers,







Movie Maker 2, Norton Internet Security™ 2005

Windows Movie Maker 2, Norton Internet Security™







(includes free Internet updates for 90 days)

2005 (includes free Internet updates for 90 days)















Bundled hardware

AC adapter, D-Connector to SCART cable, antenna cable,

registeredeither

notice.without



Remote Control, Monitor-in cable, modem cable, s-Video cable

















Special features

AV buttons (Internet, QosmioPlayer, Play/Pause,

AV buttons (Internet, QosmioPlayer, Play/Pause,







Stop, Rewind, Forward, Record, Brightness,

Stop, Rewind, Forward, Record, Brightness,







Zoom-out, Zoom-in), QosmioEngine for advanced

Zoom-out, Zoom-in), QosmioEngine for advanced







video experience, QosmioPlayer for instant-on

video experience, QosmioPlayer for instant-on

___WindowsandMicrosoftJan06.DataSG20-QosmioF20DB-EN are

tosubjectallareavailabilitycomponent/optionssystem,change



entertainment, HD to go – mobile High Definition viewing

entertainment, RAID0 and RAID1 support for





data backup and realtime disk mirroring,





HD to go – mobile High Definition viewing



















Security features

BIOS password, HDD password on request, keyboard lock, main hard disk (by screw),







main memory (by screw), slot for Kensington Cable Lock, supervisor password,







system password security, user password, Wireless LAN switch















Physical dimensions

W x L x H: 378 x 285 x 43 mm, weight: 3.30 kg

W x L x H: 406 x 285 x 43.1 mm, weight: 4.30 kg















Warranty

2-year international warranty. Upgrade your standard warranty with Toshiba warranty extension







and uplift packs. Contact your nearest Toshiba Authorised Reseller for details.





• CPU performance may vary from specifications under certain conditions such as the use of battery instead of AC power, certain external





peripherals, certain multimedia applications or network connections, complex modeling software and in areas with low air pressure at high





altitude (1,000 metres above sea level) and/or certain temperatures. CPU performance may also vary from specifications due to design





configuration. Under some conditions, your computer may automatically shut down as a normal protective measure. To avoid risk of lost data,





please make periodic back-up copies. For optimum performance, use your computer only under recommended conditions. Please read detailed





restrictions in the product resource guide, visit the Toshiba web site: computers.toshiba-europe.com and/or contact Toshiba Technical Support.





• One GB means one billion bytes, accessible capacity may be less. • For information about upgrading your system memory please refer to the





user manual or contact your local Toshiba service provider. • Wired and wireless communication capabilities to be applied in countries where

No.

and

approved. • Battery life may vary depending on applications, power management settings and features utilized. Recharge time varies depending

on usage. Battery may not charge while computer is consuming full power. After a period of time, the battery will lose its ability to perform at

JanuaryTEG2006, Art.

configurations,prices

model may not have all the features and specifications corresponding to all of the icons or switches shown on the notebook chassis.

maximum capacity and will need to be replaced. This is normal for all batteries. To purchase a new battery pack, see your accessories information





that shipped with your computer or visit the Toshiba web site at computers.toshiba-europe.com. • Small bright dots may appear on your TFT display when you turn on your PC. Your display contains an extremely large number of thin-film transistors (TFT) and is manufactured using high-precision technology. Any small bright dots that may appear on your display are an intrinsic characteristic of the TFT manufacturing technology. • Weight may vary depending on product configuration, vendor components, manufacturing variability and options selected.

• SRS® TruSurround XT™ is only available for WinDVD applications. SRS® WOW™ is only available for Windows Media Player 9 in standard Windows interface. Please check your system specifications to ensure optimal results. • Microsoft® Office OneNote™ 2003 is not available in all countries. • Certain notebook chassis are designed to accommodate all possible configurations for an entire product series. Your selected

Interested in learning more?

Please visit www.my-qosmio.com

The world’s smartest entertainment series with TV, audio, HDD/DVD recorder and PC.

January 2006

Qosmio – bringing your digital worlds together

Unlike anything you’ve seen or heard before – the Qosmio is a revolutionary new portable home entertainment series. Born of the convergence of the AV and PC worlds, the Qosmio F20 with a 15.4-inch widescreen display and Qosmio G20 with a 17-inch widescreen display are your 4-in-1 solution for digital entertainment and mobile computing.

Radical digital media, radical design

Qosmio was designed with home aesthetics in mind.



Because it thinks like a home entertainment centre,



nearly all external cables can be plugged into



the back of this thoughtfully designed unit

4-in-1

to ensure clean, uncluttered lines. The

innovation

Qosmio series is the hottest design





Qosmio combines high-

concept on the market, whether





you use it with other electronic





quality TV, HDD recording and

devices or as a stand-alone





playback, superlative audio and

system.



powerful mobile computing. Now









you can surf, game, watch TV or







DVDs, listen to music and record your







favourite shows for viewing later, all





through a single system.













































IT’S AN LCD

Qosmio F20

TELEVISION.

15.4-inch widescreen









display













IT’S AN HDD/DVD

RECORDER.

IT’S A VIRTUAL SURROUND

SOUND SYSTEM.

IT’S A POWERFUL

AND VERSATILE PC.

Page 1 Page 2
Page 1
Image 1
Toshiba F20-141 warranty Images are brought to life, Simplicity comes from intuitive design, Interested in learning more?
Page 1 Page 2

F20-141, F20-155 specifications

The Toshiba F20-155 and F20-141 are part of the well-regarded F20 series of laptops that have been designed to cater to a variety of user needs, balancing performance, mobility, and battery life. These models are particularly notable for their durable construction and user-friendly features, making them suitable for both professional and personal use.

The Toshiba F20-155 is a versatile laptop equipped with a powerful processor that ensures smooth multitasking capabilities. It features an Intel Core processor, which provides excellent performance for a wide array of applications, from office productivity tools to multimedia playback. The laptop supports up to 8GB of RAM, enabling users to run multiple applications simultaneously without experiencing significant slowdowns.

In terms of display, the F20-155 boasts a 15.6-inch LED-backlit screen, delivering vibrant colors and sharp visuals. This makes it ideal for viewing high-definition content and provides a pleasing experience for multimedia consumption. The integrated graphics card enhances visual performance, making it suitable not just for work but also for light gaming and graphic design tasks.

The F20-141 model also incorporates similar components as the F20-155, featuring a sleek design that is both lightweight and portable. This makes the F20-141 particularly appealing for students and professionals who are often on the go. The device comes with ample storage options, typically starting from 500GB, allowing users to store a significant amount of data, including documents, photos, and videos.

Battery life is another standout characteristic of these models. Toshiba has designed the F20 series with energy efficiency in mind, ensuring that users can work or enjoy media without frequent recharging. The F20-155 and F20-141 laptops are equipped with advanced battery management technology, extending usability hours between charges.

Connectivity options on the F20 series laptops include multiple USB ports, HDMI output, and a card reader, providing the flexibility to connect to various peripherals and devices. Integration of Wi-Fi and Bluetooth capabilities ensures that users can stay connected to the internet and other devices effortlessly.

Overall, both the Toshiba F20-155 and F20-141 models deliver a well-rounded computing experience, combining performance, display quality, and portability, making them excellent choices for a variety of users.
