LINER PARTS

For Models: ER8AHKXRQ02, ER8AHKXRB02, ER8AHKXRL02, ER8AHKXRS02

(White)

(Black)

(Satina)

(Stainless Steel)

Illus. Part

No. No. DESCRIPTION

1Liner (Not A Serviceable Part)

2939962 Rivet

32252837 Cover, Air Diffuser

42303825 Adaptive Defrost Control

5489174 Screw

62263075 Gasket, Air Duct

72262434 Wire Assembly Control Box

82162085 Socket, Light

92197404 Fan Support Bracket

102197405 Fan Mounting Bracket

112169142 Fan Blade

122263083 Control Box

132325701 Thermostat

14489399 Screw

Illus. Part

No. No. DESCRIPTION

151118680 Thermostat Tube

Barrier

162264715 Cover, Evaporator

172252970 Light Bulb

189791702 Light Shield

191118894 Rocker Arm Switch

202217784 Cover, Hole

212319444 Wiring, Freezer (Includes Item 32)

222202885 Control Knob

239790408 Air Tower

242197052 Hood And Foil Assembly

252261978 Cover, Air Return

262252834 Air Diffuser

27941839 Hole Plug

282264462 Grommet, Motor

29489478 Screw

302201212 Evaporator Fan

Motor

Illus. Part

No. No. DESCRIPTION

312262178 Screw

322266067 Defrost, BI−Metal

332252846 Gasket, Body Air Diffuser

362256983 Rivet

37488693 Screw

38489442 Screw

402256958 Insulation (4)

412263082 Grill (4)

422261879 Wiring Harness, Freezer Light

432256949 Light Holder

442256948 Deflector, Light

452263413 Light Socket

46R−31244 Light Bulb

472256946 Cover,

Light Holder

482256947 Lens, Light

492252831 Air Duct Assembly

6

W10154410

Page 6
