Xerox 380 Configuration, Recommended Optional Equipment, Print Mode, Color Matching, Languages

Phaser® 380 The Color Printer Designed for Designers

Configuration	Base	Extended Features
Print Resolution	300 dpi	600 x 300 dpi
Memory (RAM)	16 MB	48 MB
Resident Fonts	39	69
Check Print Preview	-	Standard
Pipeline Printing	-	Standard
Collation Printing	-	Standard*
Copystation Support	-	Standard**
Supplies	Introductory Set	Full Set

Check Print Preview† A single print preview of multiple-print projects. After review, continue or cancel printing.

Print Collation†* provides collated copies of multiple-page documents, printed in page order.

Job Pipelining† overlaps print processing several pages ahead of printing, for optimum throughput.

†Requires Extended Features Firmware. *Requires Z350 external hard disk. **Requires Phaser Copystation.

Recommended Optional Equipment

PhaserShare™ Network Card		Phaser 380 Printer Station
Lower Paper Tray Assembly		Supplies Startup Kit
Print Speeds (Pages per minute)
Print Mode	A/A4 Paper	Tabloid/A3/Tabloid Max.	A/A4 Transparency
Fast Color	3.5 ppm	2 ppm	NA
Standard Color	2.5 ppm	1.3 ppm	1.5 ppm
Enhanced Color	1.2 ppm	.6 ppm	.6 ppm

Color Matching

Built-in TekColor™ Dynamic Correction color profiles for Commercial Press, SWOP, SNAP, Euroscale, Toyo, Dai Nippon, Fuji, or Simulate Display for web site design.

Color Standards

PANTONE®*-approved solid color simulations, Adobe PostScript device- independent color, CIE international color standards, and support for ICC and Apple ColorSync color management systems.

* Pantone Inc.’s check-standard trademark for color reproduction and color reproduction materials.

Duplex Printing

Support for manual feed two-sided printing.

Languages

Genuine Adobe® PostScript®, HP-GL™ , and PCL® 5 (monochrome) emulation. Automatic sensing and switching.

Controller

33-MHz AMD RISC processor.

Workgroup Connectivity

Macintosh, Windows/DOS, NT, OS/2 PCs, and UNIX workstations.

Network Interfaces

Bi-directional parallel port	Standard
SCSI port for font/collation disk	Standard
PhaserShare™ Network Cards
Ethernet (EtherTalk®, Novell® NetWare®, TCP/IP)	Optional
Token Ring (Novell NetWare, TokenTalk, and TCP/IP)	Optional
LocalTalk and Serial	Optional

Note: PhaserShare network cards include printer management software for Windows users on Novell NetWare networks. All ports and protocols are simultaneously active with automatic print queue management.

PhaserLink™ Software Tektronix PhaserLink software provides printer status, configuration, Intranet support, and Tektronix’ support via standard web browsers.

Input Tray Capacities

Universal Tray (250 sheets)

Optional Lower Paper Tray Assembly with second Paper Tray (250 sheets)

MICROSOFT

TMWINDOWS

COMPATIBLE

Media Sizes - Tray Feed

Executive	7.25” x 10.5”
A (Letter)		8.5” x 11”				A4					210 x 297 mm
Legal		8.5” x 14”				Legal					216 x 356 mm
B (Tabloid)		11” x 17”				A3					297 x 420 mm
Tabloid Maximum 13” x 18.5”						Tabloid Maximum					332 x 471 mm
#6 Envelope	3.6” x 6.5”					C6 Envelope					162 x 114 mm
#10 Envelope	9.5” x 4.1”					DL Envelope					220 x 110 mm
Media Sizes - Manual Feed
4 x 6 to 13 x 18.5 in. (102 x 152 to 332 x 471 mm)
Paper Weights
Paper Type			Tray Feed						Manual Feed
Book and Text	40	- 120 lb. (			59 - 178 g/m2)		30	- 120 lb. (			44 - 178 g/m2)
Bond	16	-	40 lb. (		61 - 158 g/m2)		13	-	40 lb. (		49 - 158 g/m2)
Cover	50	-	65 lb.	(135 - 176 g/m2)			50	-	80 lb.	(135 - 216 g/m2)
Bristol	67	-	80 lb.	(148 - 178 g/m2)			67	-	80 lb.	(148 - 178 g/m2)
Index			90 lb.	(163 g/m2)			90	- 110 lb.		(163 - 203 g/m2)
Tag			100 lb.	(163 g/m2)			100	- 125 lb.		(163 - 203 g/m2)

Printer Drivers

Standard: Macintosh and Windows, PhaserPrint™ direct download from

Photoshop™; Optional: Workstations — SUN, SGI, HP, IBM, and DEC.

Conservation

EPA Energy Star standby mode.

Leasing Options

See your Tektronix Dealer for leasing plan options.

Warranty/Support

One year on-site warranty, toll-free telephone support, online technical support via the World Wide Web, on-demand fax reference library, and a user newsletter.

Specifications
Height: 20 in. (50.7 cm)	Depth: 25 in. (63 cm)
Width: 24 in. (59.9 cm)	Weight: 220 lb. (100 kg)

Phaser Copystation*

Original Input Color copies from originals up to

8.5x 14 in. (216 x 356 mm). Flexible cover hinge accommodates extra-thick originals. Scaling 25% to 200%.

Color Control Fine-tune individual colors. Copy Modes Color (24-bit), gray scale (8-bit), or monochrome (1-bit).

*Printer requires Extended Features configuration.

www.tek.com/Color_Printers/

Tektronix color printers are available at Tektronix Authorized Dealers worldwide. For more information or the location of your nearest Tektronix Dealer visit our web site or call:

United States and Canada (503) 682-7377 or 800-835-6100Europe (UK) +44 1628 403640

Pacific Region (Hong Kong) 852 2585 6688 (except Japan)

Tektronix®, Phaser® and ColorStix® are registered trademarks of Tektronix, Inc. TekColor™, PhaserLink™, PhaserPrint™, and PhaserShare™ are trademarks of Tektronix, Inc. TekColor CareSM is a service mark of Tektronix, Inc. Mac and the Mac OS logo are trademarks of Apple Computer, Inc., used under license. All other trademarks are the property of their respective manufacturers. PANTONE® Colors generated by the Phaser 380 printer are four-color process simulations and may not match PANTONE-identified solid color standards. Use current PANTONE Color Reference Manuals for accurate color. PANTONE Color simulations are only obtainable on these products when driven by qualified Pantone-licensed software products. Contact Pantone, Inc. for a current list of qualified licensees. The information in this document is subject to change without notice. Copyright © 1997 Tektronix, Inc. All rights reserved.

September 3, 1997 380DS-01UA-02
