Xerox 4635 IPS, 96 IPS manual alarm, IPG 3-1light, IPG

INDEX

attention

alarm, IPG 3-1 light, IPG 3-1

components, IPG 3-1–IPG 3-3 configuration options, IPG 3-6–IPG 3-9 configurations, IPG 3-4–IPG 3-5 control console, IPG 3-2–IPG 3-3 defining, IPG 8-3

dimensions, IPG 6-7–IPG 6-11 installation, IPG 8-1

IPDS bins, mapping, CMS 1-16 maintenance, IPG 8-4 performance

AS/400, IPG E-24 MVS, IPG E-16

OS/2, IPG E-34–IPG E-35 pinging

AS/400, IPG E-22–IPG E-24 MVS, IPG E-14–IPG E-15 OS/2, IPG E-32–IPG E-33

placement, IPG 6-7

power requirements, IPG 6-29–IPG 6-31 purge tray, IPG 3-1

queues

PSF/2, defining, IPG E-31–IPG E-32 resuming, CMS 2-7

sample definitions

MVS with channel attachment, IPG D-1–IPG D-3

MVS with TCP/IP connection, IPG E-1–IPG E-17

OS/2 with channel attachment, IPG D-4–IPG D-5

VM with channel attachment, IPG D-6 VSE with channel attachment, IPG D-6

sample tray, IPG 3-1

stacker trays, configuring, CMS 1-16 status, CMS 2-6

stopping, CMS 2-6

throughput speed, IPG 6-12, IPG A-3–IPG A-4, SOG A-3–SOG A-4

Printer Bins display field, CMS 1-16 printer control console

components, SOG 4-3–SOG 4-6 described, SOG 4-3

Printer Controller

components, SOG 2-1–SOG 2-5 HCU, SOG 2-1

Sun UltraSPARC workstation, SOG 2-1 description, SOG 1-2

keyboard, SOG 2-4 monitor, SOG 2-4 mouse, SOG 2-4

processor

CD-ROM drive, SOG 2-4 described, SOG 2-3–SOG 2-4 hard disk, SOG 2-3

rebooting, CMS 2-7

setting up, CMS 3-1–CMS 3-16 printer controller

components, IPG 2-1–IPG 2-10 placement, IPG 5-3–IPG 5-8

power requirements, IPG 5-9–IPG 5-10 space requirements, IPG 5-3–IPG 5-8

Printer Controller exterior, cleaning, PRM 6-1 Printer icon, SOG 4-4

printer tray cells, CMS 4-42 Printer Tray field, CMS 4-18

Printer Trays field, CMS 1-15, CMS 4-41 printers

capabilities, SOG 1-1 components, SOG 4-2–SOG 4-6

attention light, SOG 4-6 feeder/stacker module, SOG 4-7 high-capacity feeder trays, SOG 4-7

high-capacity stacker, SOG 4-7, SOG 4-10– SOG 4-11

inverter feeder/stacker module, SOG 4-7 printer control console, SOG 4-3, SOG 4-3–

SOG 4-6

processor feeder trays, SOG 4-2, SOG 4-7 purge tray, SOG 4-6

sample tray, SOG 4-6 configurations, SOG 4-12–SOG 4-13 description, SOG 1-2

paper jam areas, TRB 3-9–TRB 3-20 paper path, SOG 4-16

restarting, TRB 6-3 printing

pages remaining display, CMS 1-19 samples, CMS 4-15–CMS 4-19 test patterns, CMS 4-15

printing test jobs OS/2, IPG E-33

privilege mode, CMS 4-2 Administrator Mode, CMS 4-2 changing, CMS 1-13, CMS 4-3, CMS 4-4 display on main window, CMS 1-18 Operator Mode, CMS 4-2

Service Mode, CMS 4-2 User Mode, CMS 4-2

privilege modes, SOG 1-16 procedures

4mm cartridge tape drive, cleaning, PRM 6-1 channel connection, switching, CMS 3-3–CMS

3-5

CMS = Guide to Configuring and Managing the System

IPG = Installation Planning Guide

PRM = Guide to Performing Routine Maintenance

SOG = System Overview Guide

TRB = Troubleshooting Guide

INDEX-8 MASTER INDEX FOR MODEL 96/4635/180 IPS
