Generac Portable Products SE10000 Generator

GENERATOR PARTS LIST

Item

Part #

Qty

Description

Item

Part #

Qty

Description

1

NSP

1

ENGINE, Robin 18HP

41

B4627

1

KEY, Ignition Switch

2

BB4509

1

SHIELD, Heat

42

AB4682

1

BRACKET, Ignition Switch

3

A77304

2

SUPPORT, Engine

43

A96925

1

BRACKET, Battery Tie Down

4

BB4811

1

SHIELD, Heat

44

96924

2

J-BOLT, M8 - 1.25

5

80270

1

VALVE, Fuel Shut-Off

45

193-53621 1

CABLE, Battery Positive

6

78299

1

BUSHING, Fuel Valve

46

194-53621 1

CABLE, Battery Negative

7

B4325

1

CAP, Fuel Tank

47

52618

2

HHCS, M5 - 0.8 x 12

8

38353

6

MOUNTS, Vibration

48

49226

1

WASHER, M5 Lock

9

78831B

4

CAPSCREW, M6-1.0 x 60mm

49

52856

2

NUT, M5 Flange Lock

10

B1696

1

TANK, Fuel 10 Gal

50

49820

2

NUT, Nylok M8 - 1.25

11

AB4426

1

CRADLE

51

39253

1

CAPSCREW, M8 - 1.25 x 20

12

83465

4

GROMMET, Mounting

52

NSP



SUPPLIED WITH ENGINE

14

23152

7

CAPSCREW, 3/8-16 x 3/4"

53

45771

1

NUT, M8 - 1.25

15

22237

20

WASHER, 3/8" Lock

54

27482

1

WASHER, 5/16" Shakeproof

16

22241

10

NUT, 3/8"-16 Hex

55

47411

2

CAPSCREW, M6 - 1.0 X 16

17

22746

4

CAPSCREW, 3/8-16 x 1-3/4"

56

22473

2

WASHER, Flat M6

18

22131

8

WASHER, 3/8" Flat

57

B4948

1

CLAMP, Hose

19

BB5117

1

SHIELD, Heat

58

55934G

2

CLAMP, Hose

20

B4425

1

ASSEMBLY, Control Panel

59

22511

4

CAPSCREW, 3/8 x 1-1/4"

21

195-53621 1

WIRE ASSEMBLY, Ground

60

B4803

1

CONNECTOR, 5-way

22

38750

1

HHCS, M6 - 1.0 x 30

61

52618

1

HHCS, M5 - 0.8 x 12

23

B4502

1

SWITCH, Key Ignition

62

B4794

2

GROMMET, Generator Cover

24

22145

2

WASHER, M8 Flat

63

B2153

17

SCREW, #12 Self Driller

25

26850

3

WASHER, M6 Shakeproof

64

B4988

1

DECAL, Oil Fill

26

20566

1

DECAL, 1-800

65

52857

1

NUT, Locking M6 - 1.0

27

B4986

1

DECAL, Ground

66

87680

1

WING NUT, M6 - 1.0

28

92982

1

DECAL, Danger

67

23897

2

WASHER, M5 Lock

29

B4865

1

DECAL, Side Panel

68

49813

1

NUT Hex M6 - 1.0

30

B4866

1

DECAL, Control Panel









31

78817

1

DECAL, Data Plate

Items Not Illustrated:



32

77816

2

DECAL, Caution Hot Muffler



33

B4826

1

DECAL, Start Instructions



BB3061

2

SAE 30 Oil

34

B4824

1

DECAL, Start - Run - Stop



B3518

1

Oil Bottle Funnel

35

79552

1

DECAL, Overlaminate



37806

1

125 Volt 30 Amp Plug

36

73054

1

DECAL, Fuel Shut-Off



43438

1

240 Volt 30 Amp Plug

37

B4268

1

ALTERNATOR, 10KW



93568

1

125 Volt 20 Amp Plug

38

BB4481

1

GUARD, Muffler



B4472

1

Owner’s Manual

39

20441

4

SCREW, 1/4" x 3/4" Self



B4888

1

Generator Reference Card







Driller



NA

1

Engine Owner’s Manual

40

B4489

1

BATTERY









19
