Philips FWV595 manual Controls

Controls

$MIC/LEVEL

Ðto connect microphone jack.

Ðto adjust the mixing level for karaoke or

microphone recording.

%ç

Ðto open the tape deck door.

^ TAPE DECK 2 & TAPE DECK 1

* SOURCE Ð to select the following:

VCD PAL/NTSC / (CD 1•2•3)

Ðto select disc tray 1, 2 or 3 (this system can playback normal CD/VCD/MP3-CD format disc).

Ð(on the system only) to select corresponding video output for NTSC or PAL system of your TV set (except Multi-system TV).

TUNER / (BAND)

Ðto select waveband : FM or MW.

TAPE / (TAPE 1• 2)

Ðto select tape deck 1 or 2.

AUX / (CDR/DVD)

Ðto select a connected external source : CDR/DVD or AUX (auxiliary) mode.

(Mode Selection

PLAY PAUSE ÉÅ

for CD/VCD/MP3-CDÉto start or interrupt playback.

for TAPE .............. to start playback.

for PLUG & PLAYÉ(on the system only) to initiate and start plug & play mode.

SEARCH• TUNING à á

(ALBUM -/+)

for MP3-CD onlyÉto select previous/next Album

for VCD onlyÉto move the zoomed picture to

the left or right.

for CD/VCD .... to search backward/forward. for TUNER ........ to tune to a lower or higher

radio frequency.

for TAPE .............. to rewind or fast forward. for CLOCK ....... (on the system only) to set the

hour.

DEMO STOP/CLEAR Ç

for CD/VCD/MP3-CDÉto stop playback or to

	clear a programme.
for TUNER	(on the system only) to stop
	programming.
.................................	(on the system only) to delete
	the preset radio station.
for TAPE	to stop playback or recording.
.................................	to reset tape counter number.
for DEMO	(on the system only) to activate/
	deactivate the demonstration.
for CLOCK	(on the system only) to exit clock
	setting or cancel timer.

for PLUG & PLAYÉ(on the system only) to exit

plug & play mode.

PREV / PRESET / NEXT í ë

(TITLE -/+)

for MP3-CD onlyÉto select previous/next Title. for VCD onlyÉto move the zoomed picture

	down or up.
.................................	to select next or previous
	MENU or VCD track during
	playback (for VCD with PBC
	switched on).
for CD/VCD ....	to skip to the previous or next
	track.
for TUNER	to select a preset radio station.
for CLOCK	(on the system only) to set the
	minute.

)n

Ðto connect headphones.

¡VCD Operation (for VCD version 2.0 only)

PBC (PLAYBACK CONTROL)

Ðto switch on or off PBC mode.

RETURN

Ðto return to the previous MENU level during

playback (for VCD with PBC switched on).

™TITLE/ALBUM NAME

Ðto display the title or album name for

MP3-CD.

£DISPLAY

Ðto select different screen display mode :

NORMAL, MODE 1, MODE 2, or MODE 3.

24PROG

for CD/VCD/MP3-CDÉ to programme disc

	tracks.
for TUNER	to programme preset radio
	stations.
for CLOCK	(on the system only) to select 12-
	or 24-hour clock mode.

E n g l i s h

11
