Philips FWV595 manual Switching the system on, Switching the system to Standby mode, Display mode

Page 14

Basic Functions

E n g l i s h

Switching the system on

In Standby/Demonstration mode

●Press STANDBY ON.

➜The system will switch to the last selected source.

●Press VCD, TUNER, TAPE, AUX (or

VCD 123/MP3 123, TUNER, TAPE 1/2 or AUX on the remote control).

➜The system will switch to the selected source.

●Press any one of the DISC DIRECT PLAY buttons.

➜The system will switch to CD mode.

Switching the system to Standby mode

In Demonstration mode

●Press and hold DEMO STOP Ç on the system.

In any other source mode

●Press STANDBY ON (or B on the remote control).

➜ The clock will appear on the display when the system is in Standby mode.

Note:

–If you have not deactivated the demonstration, it will resume five seconds after the system switches to Standby mode.

Power Saving Automatic Standby

As a power-saving feature, the system will automatically switch to Standby mode if you do not press any buttons within 30 minutes after a disc or tape has stopped playing.

Display mode

There are four different display modes for selection.

●Press DISPLAY repeatedly to select NORMAL, MODE 1, MODE 2, or MODE 3.

NORMAL ........ All available LEDs will light up and the display screen will have full brightness. The VU meter will be in music mode.

MODE 1

.......... All available LEDs will light up



and the display screen will have



full brightness. The VU meter will



be in volume mode.

MODE 2

.......... All available LEDs will light up



and the display screen will be at



half brightness. The VU meter



will be in music mode.

MODE 3

.......... The display screen will be at half



brightness. The VU meter and all



LEDs will be off.

Volume Control

Adjust VOLUME to increase (turn knob clockwise or press VOLUME +) or decrease (turn knob anti-clockwise or press VOLUME -) the sound level.

To listen through the headphones

●Connect the headphones plug to the n socket at the front of the system.

➜ The speakers will be muted.

Sound Navigation

For optimal sound listening, select only one of the following navigation sound controls at a time : MAX sound, DSC or VAC.

MAX Sound

MAX sound provides the best mixture of various sound features (DSC,VAC, DBB for example).

●Press MAX SOUND (or

MAX ON/OFF on the remote control) repeatedly

to activate/deactivate the optimal sound.

➜If activated, will appear on the display and the MAX SOUND button lights up.

➜If deactivated, ÒMAX OFFÓ will be displayed.

Note:

–When MAX sound is selected, all other sound navigation will switch off automatically.

14

Page 13 Page 15
Image 14
