Philips 192E1SB/00 user manual Automatic Power Saving, Factory preset modes

Page 26

Product Information

1366x768 at 60Hz(digital input)

10 factory preset modes:



























H. freq (kHz)



Resolution



V. freq (Hz)



31.47

720*400

70.09



31.47

640*480

59.94



37.50

640*480

75.00



37.88

800*600

60.32



46.88

800*600

75.00



48.36

1024*768

60.00



60.02

1024*768

75.03



63.89

1280*1024

60.02



79.98

1280*1024

75.03



47.71

1366*768

59.79

















RETURN TO TOP OF THE PAGE

Automatic Power Saving

If you have VESA DPM compliance display card or software installed in your PC, the monitor can automatically reduce its power consumption when not in use. If an input from a keyboard, mouse or other input device is detected, the monitor will 'wake up' automatically. The following table shows the power consumption and signaling of this automatic power saving feature:

Power Management Definition

VESA Mode

Video

H-sync

V-sync

Power Used

LED color

Active

ON

Yes

Yes

< 35 W (typ.)

Green

Sleep

OFF

No

No

< 0.5 W

Amber

Switch Off

OFF

-

-

< 0.5 W

Off
