Xerox M123/M128 manual Ldap Setup

Page 11

LDAP Setup

Field Name

Description

Location

Value

Directory Server

Enable LDAP





(LDAP)















Primary Server

The Primary IP address of the LDAP



_____._____._____._____



server or server Name. If server name



Ex: 192.168.1.2



is used, ensure that DNS information is



OR



properly populated via Centreware



Ex:<name>.<company>.com



Internet Services.





Primary Server Port

Port number of the primary LDAP





Number

Server

LUI:

Ex: Port 389









System Settings Æ System Settings



Secondary Server

The Secondary IP address of the LDAP





server or server Name

Æ E- Mail / Fax Settings Æ

_____._____._____._____





Address Search (Directory Service)

Ex: 192.168.1.2







OR







Kerberos.<company>.com

Secondary Server

Port number of the primary LDAP





Port Number

Server



Ex: Port 389







Login/password

Login and password information







required connecting to the LDAP







server. Note: most LDAP servers don’t







require authentication, and therefore







the login and password is usually







optional.





Page 11 of 28

701P42081
